Product Overview
Description
Product Description
Solar Pumping System overview
The solar pumping system is composed of a PV generator, a pump and a solar pump inverter. Based on the design philosophy that it is more efficient to store water rather than electricity, there is no energy storing device such as storage battery in the system. The system is prepared to be combined with a elevated water storage, e.g. water tower or an uphill tank installation.
The PV generator, an aggregation of PV modules connected in series and in parallel, absorbs solar irradiation and converts it into electrical energy, providing power for the whole system. The pump drive controls and adjusts the system operation and converts the DC produced by the PV module into AC to drive the pump, and adjusts the output frequency in real-time according to the variation of sunlight intensity to realize the maximum power point tracking (MPPT). The pump, driven by 1/3-phase AC motor, can draw water from deep wells, rivers and lakes and pour it into storage tanks or reservoirs, or be connected directly to the irrigation system, fountain system, etc. According to the actual system demand and installation condition, different types of pumps such as centrifugal pump, axial flow pump, mixed flow pump or deep well pump can be used.
The PV generator, an aggregation of PV modules connected in series and in parallel, absorbs solar irradiation and converts it into electrical energy, providing power for the whole system. The pump drive controls and adjusts the system operation and converts the DC produced by the PV module into AC to drive the pump, and adjusts the output frequency in real-time according to the variation of sunlight intensity to realize the maximum power point tracking (MPPT). The pump, driven by 1/3-phase AC motor, can draw water from deep wells, rivers and lakes and pour it into storage tanks or reservoirs, or be connected directly to the irrigation system, fountain system, etc. According to the actual system demand and installation condition, different types of pumps such as centrifugal pump, axial flow pump, mixed flow pump or deep well pump can be used.
Solar pump system constitution. It includes solar panels arrays, solar pump inverter and AC pumps.
Dual supply mode - Dolar DC and Grid AC Compatiable input.
Dual supply mode - Dolar DC and Grid AC Compatiable input.
Main Features of solar pump inverter
Maximum power point tracking (MPPT) with fast response speed and stable operation efficiency> 99%;
Suits for most 3 phase AC pumps and AC PMSM high efficiency pumps.
The working voltage of solar panel can set by manual or MPPT automatically tracking
Compatible with dual power input, AC grid and DC power supply input.
Built in automatic sleep-wake up function,
Dry run (under load ) protection
Motor maximum current protection
Low input power protection
Lowest stop frequency protection
The PQ (power/flow) performance curve enables calculating the flow output from the pump
Digital control for fully automatic operation, data storage and protective functions
Intelligent power module (IPM) for the main circuit
LED display operating panel and support remote control
Low water probe sensor, and water level control function
Strong lightning protection
Suits for most 3 phase AC pumps and AC PMSM high efficiency pumps.
The working voltage of solar panel can set by manual or MPPT automatically tracking
Compatible with dual power input, AC grid and DC power supply input.
Built in automatic sleep-wake up function,
Dry run (under load ) protection
Motor maximum current protection
Low input power protection
Lowest stop frequency protection
The PQ (power/flow) performance curve enables calculating the flow output from the pump
Digital control for fully automatic operation, data storage and protective functions
Intelligent power module (IPM) for the main circuit
LED display operating panel and support remote control
Low water probe sensor, and water level control function
Strong lightning protection
Solar pump inverter specification when PE-00=1&2 | ||
Recommended MPPTvoltage range | Vmp 131 to 350 VDC for 1s (80V to 350VDC input, 3PH 110 to 220VAC output) Vmp 260 to 355VDC for 2S/ 2T ( 150V to 350VDC input, 3PH 220 to 240VACoutput) Vmp 486 to 650 VDC for 4T ( 250V to 800VDC input, 3PH 380 to 460VACoutput) | |
Recommended inputVoc and Vmp voltage | Voc 180(VDC), Vmpp 155(VDC) for 1S model or 110V AC pumps Voc 380(VDC), Vmpp 310(VDC) for 2S model or 220V AC pumps Voc 650(VDC), Vmpp 520(VDC) for 4T model or 380V AC pumps | |
Motor type | Control for permanent magnet synchronous motor and asynchronous motor pumps. | |
Rated output voltage | 1/3-Phase,110V/160V/220V. 3-phase, 220V/380V/460V | |
Output frequency range | 0~maximum frequency 600Hz. | |
MPPT efficiency | Above 99.0% | |
Ambient temperaturerange | G type for submersible pumps, 150% rated current for 60s, 180% rated current for 2s . P type for general pumps, 120% rated current for 60s, 150% rated current for 2s | |
Solar pump controlspecial performance | MPPT ( maximum power point tracking), CVT (constant voltage tracking), auto/manual operation, dry run protection, low stop frequency protection, minimum power input, motor maximum current protection, flow calculating, energy generated calculating and water tank level detected | |
Protection function | Phase loss protection, phase short circuit protection, ground to phase circuit protection , input and output short circuit protection. Stall protection, lightning protection | |
Protection degree | IP20, Air force cooling | |
Running mode | MPPT or CVT | |
Altitude | Below 1000m; above 1000m, derated 1% for every additional 100m. | |
Enhanced version of ACdrive | CE, Design based on vector control motor AC drive, more specification please refer to S600 or S600 vector control drive operation manual | |
Technical specification of variable frequency inverter when PE00=0 (solar pump disable) | ||
Voltage, frequency | 1 phase 220V, 3 phase, 220V,380V, 660V, 0-50/60Hz | |
Control mode | 0: VF control ; 1: Open loop vector control mode2: Close loop vector control mode | |
Maximum frequency | 0-320Hz in vector control mode, 0~3200Hz in VF control mode | |
Multiple-functions | PID Control, Carrier Frequency Adjustable, Current Limiter, Speed Search,Momentary Power Loss Restart,16 Step Speed (Max), 3-Wire connection, SlipCompensation, Frequency Jump, DC braking, Upper/Lower Frequency,Torque control, Compatible for PMSM and IM, built in RS485, counting, faultinformation checking, fully fault protection function, frequency combinationreference | |
Related products
Company Profile
Exhibition
Customer Photos
