Continuous scrap tyre recycling to oil machine pyrolysis plant
- Category: >>>
- Supplier: Henan Lanning Technology Co. Ltd.
Share on (60735814005):
Product Overview
Description
Continuous scrap tyre recycling to oil machine pyrolysis plant
Plant information
1. The Raw Material For Pyrolysis Machine
NO. | Raw material | Note |
1 | Waste tyre | Steel tyre ,Nylon tyre ,Bick tyre |
2 | Waste plastic | PE,PVC,Waste washed mixture plastic from waste Paper Factory |
3 | Waste rubber | Shoes Soles,Cable Skin |
4 | oil sludge,waste oil sludge |
|
We have our own lab to test the oil output rate of your raw material ,welcome you contact | ||
2. Pyrolysis plant models and specification
Product Model | Specifications | Per batch capacity | Per day output | Containers | Gross weight | Power |
LN-2200*6000 | 2200mm*6000mm | 6ton | 3ton | 2*40HQ | 25ton | 12kw |
LN-2200*6600 | 2200mm*6600mm | 7ton | 4ton | 2*40HQ | 27ton | 12kw |
LN-2600*6000 | 2600mm*6000mm | 8ton | 5ton | 1*40HQ&1*FR | 30ton | 16kw |
LN-2600*6600 | 2600mm*6600mm | 10ton | 6ton | 1*40HQ&1*FR | 33ton | 17kw |
LN-2800*6000 | 2800mm*6000mm | 10ton | 6ton | 1*40HQ&1*FR | 36ton | 17kw |
LN-2800*6600 | 2800mm*6600mm | 12ton | 7ton | 1*40HQ&1*FR | 39ton | 17kw |
3.The available fuel for pyrolysis processing
NO. | Fuel |
1 | Oil(fuel oil, tyre oil, heavy oil etc..) |
2 | Natural gas |
3 | Coal |
4 | Firewood |
5 | Carbon black pellet |
4. End product percentage and useage( Example : raw material is tyre)
NO. | Name | Percentage | Usage |
1 | Tyre oil | 45% | * can be sold directly. * make diesel and gasoline by use oil distillation machine. * can be as fuel. |
2 | Carbon black | 30% | * can be sold directly. * make fine carbon by use carbon black refining machine. * make pellet by use carbon make pellet machine. |
3 | Steel wire | 15% | * can be sold directly. * make steel bloom by use hydraulic press-packing |
4 | Oil gas | 10% | * can be as fuel burn by use gas burn system (pyrolysis machine included) *extra gas also be storage as fuel for other heating. |
5. Pyrolysis machine advantage and main technical characteristics
1. High oil output rate 45%--55% with special catalyst formula and high tech .
2. Rapid condensers and large cooling area,assure you get much more and higher quality oil.
diversiform cooling system can be choose according to client's willingness
3. Dust-removing device -four levels dust processing system make sure no any population and the
output smoking is the spray .more environmental protection.
4. Double tail-gas recycling and burning system, saving energy.
5. Q245R boiler plate, high temperature resistance, thickness reaches 14mm—16mm,guarantee
4-7 years service lives. and optional plate is Q345R
6. OptionalAuto feeder and carbon black discharge elevator, high automation, saving time and labors.
7. Eco-friendly and no any population, environmental protection
6.Machine 3D drawing flow chart and working processing
Apare parts
Final products
Packaging & Shipping
The machine can delivery within 15 working days after receiving deposit
Installatation
Company Information
1) History:
Founded in 2006 with Ningling Lanning Technology Co.,LTD.
Renamed in 2017 by Henan Lanning Technology Co.,LTD
2) Location:
Located in Ningling county, Shangqiu city, Henan province, China.
3) Main Products:
Tyre/ Plastic Pyrolysis machine;
Oil distillation machine;
Carbon black make pellet machine;
4) Certification:
ISO 9001
CE (International exports to the European Union certification)
BV (French authority certification)
TUV (Germany authority certification)
