Max.dia.Of workpiece ( without back column/with back column) mm
500/500
800/550
Max. modulus mm
8/6
10/8
Max machining width mm
350
500
Minimum hobbing gear teeth (Z/K)
5
7
Max. travel of carriage in vertical direction mm
430
530
Max. helix angle in turning bevel gear
±45°
±45°
Distance between axis of cutter and work table face mm
235~665
235~765
Spindle Taper
MT.5
MT.5
Max. dimension of cutter mm
Φ160×180
Φ160×180
Max. axial movement of cutter mm
180
Diameter of changeable hobbing arbor mm
22,27,32
27,32,40
distance from hob center to worktable center mm
30~330
50~550
Rapid moving speed of work table mm
50
50
External Diameter/bore diameter of work table mm
510/80
650/80
spindle speed steps
9
8
spindle speed range rpm
40~250
40~200
axial feeds range mm/rev
12-step 0.4~4
12-step 0.4~4
power of main motor synchro-speed kw/rpm
4/1500
5.5/1500
power of rapid axial motor synchro-speed kw/rpm
1.1/1500
Power of rapid worktable motor synchro-speed kw/rpm
1.1/1000
1.1/1000
Power of Pump motor synchro-speed kw/rpm
4500
5800
Net Weight kg
4500
5800
Overall Size mm
2440×1270×1920
Company Introduction
FAQ
Q1.How to send my enquiry? You can contact us by email, phone call, message (Whats APP, We Chat, Skype). Q2.How long can I get feedback after enquiry? We will reply you within 3 hours in working day. Q3.Delivery time Machines order takes 30 days after deposit payment received. Please inquiry sales. Q4.What is the package? Is it suitable for shipment? Machine is by waterproof cloth to covered. And be packed by standard exported wooden case with steel foot. It is very much strong for oversea transportation. Q5.Payment term 30% T/T as down payment, balance 70% by T/T before delivery. If others payment terms, we can discuss the details. Welcome to inquiry sales. Q6.How long is the warranty for machines? Machines warranty is 12 months after receive goods. in Warranty time,we can provide new free parts for changing. Q7.Can you engineer come to our place to help with machine installation & commission? Yes, our engineers are available to travel to your place. Round flight tickets & accommodation will be at your cost.
