5kva Solar Pure Sine Wave Inverter Hybrid Solar Inverter With Mppt Solar Controller and AC charger Wholesale From Of China
- Category: >>>
- Supplier: Shenzhen King Sako Electronics Co. Ltd.
Share on (60736189956):
Product Overview
Description
Details Images
5kva Solar Pure Sine Wave Inverter Hybrid Solar Inverter With Mppt Solar Controller and AC charge Wholesale From Of China
MAIN FEATURES
1. Real MPPT charge controller built inside,15%-20% higher than PWM charge controller, use solar utmost. 2. Pure sine wave, high frequency technology,wall amounted design,light weighted and easy to operate 3. Selectable input voltage range for home appliances and personal computers
4. Selectable charging current based on applications
5. Configurable AC/Solar input priority via LCD setting
6. Compitable to grid power or generator power
7. Parallel operation with up to 6 units only available for 4KVA/5KVA
8. Auto restart while AC is recovering, auto charge and switch, unattended operation 9. Smart battery charger and management for optimized battery performance
10. Remote control panel is optional
11. High Efficient DC-To-AC Conversion.Minimizing Energy Loss and self power consumption 12. All around protection functions: Overload/short circuit protection/high voltage/low battery voltage/high temerature,etc.
Model | SUNSEE-3K | SUNSEE-5K | ||
The rated power | 3000VA/2400W | 5000VA/4000W | ||
INPUT | ||||
Voltage | 230 VAC | |||
Selectable Voltage Range | 90-280VAC (For Personal Computers), 170-280VAC (For Home Appliances) | |||
Frequnecy Range | 50Hz/60Hz (Auto sensing) | |||
OUTPUT | ||||
AC Voltage Regulation (Batt. Model) | 230VAC ± 5% | |||
Surge Power | 6000VA | 10000VA | ||
Power factor | 0.8 | |||
Efficiency(Peak) | > 90% | |||
Transfer Time | 10ms (For Personal Computers), 20ms (For Home Appliances) | |||
Wave form | Pure sine wave | |||
No load current | 1.36A | 1.15A | ||
BATTERY | ||||
Battery voltage | 24VDC | 48VDC | ||
Low battery alarming voltage | 22.5VDC | 43.5VDC | ||
Low battery cut off protection voltage | 20.5Vdc | 41.00VDC | ||
Low battery recovery voltage | 23.5VDC | 45.5VDC | ||
Floating Charge Voltage | 27VDC | 54VDC | ||
Overcharge Protection | 32VDC | 62VDC | ||
MPPT SOLAR CHARGER & AC CHARGER | ||||
Maximum PV Array Power | 1800W | 4800W | ||
MPPT Range Operation Vol | 18-145VDC | 36-115VDC | ||
Maximum PV Array Open Circuit Vol. | 145VDC | 145VDC | ||
Standby Power Consumption | 2W | 2W | ||
Maxmum Solar Charge Current | 60A | 80A | ||
Maxmum AC Charge Current | 60A | 60A | ||
Maxmum Charge Current | 120A | 120A | ||
Maxmum Efficiency | 98% | |||
BEST PANEL CONFIGUTATION | ||||
Max. generated from solar charger | 60Amp, 1800W | 80Amp, 4800W | ||
Best Panel configuration | 250Wp*6pcs(1500wp) | 250Wp*18pcs (4500Wp) | ||
PHYSICAL | ||||
Products Dimension, D*W*H(mm) | 465*300*116 | 470.5*300*136 | ||
Packing size, D*W*H(mm) | 543*394*205 | 549*394*224 | ||
Net Weight (kgs) | N.W.: 8.4, G.W.: 10.1KGS | N.W.: 10.81, G.W.: 12.86KGS | ||
OPERATING ENVIRONMENT | ||||
Humidity | 5% to 95% Relative Humidity (Non-condensing) | |||
Operation Temperature | 0℃-50℃ | |||
Recommend Products
Buyer Feedback
Company Profile
Our Partners
Product packaging
FAQ
Q 1.Would you accept to use our logo ?
A:All of our products are accepted to print your logo on the enclosure and package box, it depends on the amount, from 200pcs to 1000pcs.
Q 2.We want to know month capacity.
A:20000-30000PCS per Month.
Q 3.how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
Q 4. What kind of certificate you have ?
A:CE/TUV/CE/ISO/CB/UL/ROHS certificates.etc.
Q5. Are you a factory or trading company?
Yes,we are factory, supplying OEM/ODM service.
Q 6.How to pay for solar controller?
A:We accept paypal, western union, T/T. If you have any good payment, we also can accept.
Q 7.How to choose suitable inverter?
A:If your load is resistive loads, such as: bulbs, you can choose a modified wave inverter. But if it is inductive loads and capacitive loads, we recommend using pure sine wave power inverter.
Q8.How do I choose the size of the inverter?
A:Different types of load demand for power are different. You can view the load power values to determine the size of the power inverter.
Q9.what can you buy from us?
A:Solar Gel Battery,Lead Acid Battery,Solar Off-grid System,Lithium Battery,Battery Balancer,Solar Panel
A:All of our products are accepted to print your logo on the enclosure and package box, it depends on the amount, from 200pcs to 1000pcs.
Q 2.We want to know month capacity.
A:20000-30000PCS per Month.
Q 3.how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
Q 4. What kind of certificate you have ?
A:CE/TUV/CE/ISO/CB/UL/ROHS certificates.etc.
Q5. Are you a factory or trading company?
Yes,we are factory, supplying OEM/ODM service.
Q 6.How to pay for solar controller?
A:We accept paypal, western union, T/T. If you have any good payment, we also can accept.
Q 7.How to choose suitable inverter?
A:If your load is resistive loads, such as: bulbs, you can choose a modified wave inverter. But if it is inductive loads and capacitive loads, we recommend using pure sine wave power inverter.
Q8.How do I choose the size of the inverter?
A:Different types of load demand for power are different. You can view the load power values to determine the size of the power inverter.
Q9.what can you buy from us?
A:Solar Gel Battery,Lead Acid Battery,Solar Off-grid System,Lithium Battery,Battery Balancer,Solar Panel
