Новинка, 9 куб. М., готовые цементные автобетономешалки, китайский грузовик с гидравлическим насосом
- Category: >>>
- Supplier: Hubei Xindongri Special Vehicle Co. Ltd.
Share on (60736612481):
Product Overview
Description
Product Description
Product Application
Concrete mixer truck is widely used to transport and mix concrete up to the construction site, such as skyscraper construction, bridge construction,high way construction and so on. Due to different size of the drum, the concrete mixer truck can be divided into different models from 2 cbm to 16cbm with different special chassis,like dongfeng, foton, dayun,jiefang and sinotruck.
Vehicle Parameters | ||||||
General | Vehicle Model | YZR5317GJBSXG6BF | ||||
Vehicle Brand | XDR | |||||
Chassis Brand | Shacman | |||||
Overall Dimension(mm) | 10300×2550×3990 | |||||
GVW/Curb/Rated loading Weight(kg) | 31000/14800/16070 | |||||
Chassis Parameters | ||||||
Cab | Cab Seat | 2 | ||||
Air Conditioner | YES | |||||
Engine | Fuel Type | Diesel | ||||
Engine Model | WP10.380E22+PTO | |||||
Engine Brand | Weichai | |||||
Power(hp) | 380hp | |||||
Displacement(L) | 9.726 | |||||
Emmission Standard | Euro2 | |||||
Chassis | Drive Type | 8*4 | ||||
Transmission | 10 speed, Manual | |||||
Wheelbase(mm) | 1800+2975+1400 | |||||
Tyre Specification | 12.00R20 | |||||
Tyre No.(pcs) | 10+1 | |||||
Max Speed(km/h) | 80 | |||||
Paint | White | |||||
Super Structure Parameters | ||||||
Tank Volume | 15cbm | Tank Material | High wear resistant high strength alloy steel | |||
Tank Thickness | 6mm for drum;8mm for seal | Water supply | Pressure supply | |||
Charging speed | m3/min≥3 | Discharging speed | m3/min≥2 | |||
Discharge residual rate | ≤0.5(%) | Discharge range | 180degree | |||
Key Parts | PMP reducer and hydraulic pump,motor | |||||
Advantages
1) Reliable quality
2) manageable
3) remarkable economical benefits
4) Improve working condition
5) good for environmental protection and civilized construction
