Product Overview

Description

Good Reputation Wireless Shackle Load Pin,Heavy Duty Shackle Stainless Steel



Features:

•The shackle S6 grade:0.5t-1250t.

•S6 grade is structural alloy steel.

•The maximum testing load of 0.5t-150t shackle is 2 times of the working load,
the maximum testing load 200t of 500t shackle is 1.5 times of the working load.
•The maximum testing load of 800t-12500t shackle is 1.33 times of the working load, the minimum breaking load is 1.5 times of the working load.

•Monitors traction force and other force measurement

•Available in 7 standard ranges between 0.5t-1250t

•Alloy steel and Stainless steel construction

Wireless Load Links Typical Specifications:

Rate Load:	0.5t-1250t	Overload Indication:	100% F.S. + 9e
Proof Load:	150% of rate load	Max. Safety Load:	125% F.S.
Ultimate Load:	400% F.S.	Battery Life:	≥40 hours
Power On Zero Range:	20% F.S.	Operating Temp.:	- 10℃ ~ + 40℃
Manual Zero Range:	4% F.S.	Operating Humidity:	≤85% RH under 20℃
Tare Range:	20% F.S.	Remote Controller Distance:	Min.15m
Stable Time:	≤10seconds;	Telemetry Frequency:	470mhz
System Range:	500~800m (In Open Area)
Battery Type:	18650 rechargeable batteries or polymer batteries (7.4v 2000 Mah)
