4PIN DIP 1p1t detection switch/detector induction switch / SPPB512300 / SPPB530601
- Category: >>>
- Supplier: Dongguan Kemei Electronics Co. Ltd.
Share on (60737649954):
Product Overview
Description
micro detector tact switch
Detector Switch | Specification |
Rating | 0.1A 30V DC |
Contact resistance | 100mΩ max |
Insulation resistance | 100MΩ min at500V DC |
Dielectric strength | AC 500V for 1 min |
Lifespan | 100,000 Cycles |
Practical temperature range | -25 to 85 degrees Celsius |
RoHS | Yes |
[Warm Tips]All informations above are for reference only; Particulars of all items are base on individual specification. | |
Donguan Kemei Electronics Co.,Ltd.
