Rechargeable long cycle life IFR 32650 battery lifepo4 32650 3.2V 5000mah li ion polymer lithium battery 5ah

Model

GMB103450AR

Housing Material

Aluminum foil

Nominal Voltage

3.7 V

Nominal Capacity(@ 0.2C (360mA))

2000mAh

Internal Impedance

40mΩ typ. 60mΩ max.

Discharge Cut-off Voltage

2.75V/cell

Charge Cut-off Voltage

4.20±0.05V

Max Charge Current

2000mA

Max Discharge Current

2C

Charge method

CC/CV (constant current/constant voltage)

Dimension(half charged)

Thickness: 10.5+0.0 –0.5 mm Width: 34.0+0.0 –0.8 mm Height:49.0+0.0 –0.5 mm

Weight

About :37±2.0 g

Operating Temperature

Charging Temperature:             0~45℃

Discharging Temperature:     -20~60℃

Storage Temperature

-5℃~35℃(suggest 25±2℃)

Relative Humidity

65±20%

Visual Requirements

Defects, such as scratches, flaws, dirty spots, rust, deformation, discoloration, leakage, etc., whichimpact commercial values shall not be allowed.

Shipping Voltage

3.70-3.90V(about 50% capacity)

Storage Voltage

3.70-3.90V

If  the  cell  has  been  storage  over  half years, charge  the  cell  with  0.5CmA  or

1CmA of constant current and 3.9V constant voltage until the Charge cut-off current of 0.01 C5mA is achieved.

Environmental Request

The materials of the product and packaging are

RoHS compliant.
