From 184 to 454 chassis | ||||||||
Models | 184(180) | 204(200) | 254(250) | 284(280) | 304(300) | 354(350) | 404(400) | 454(450) |
Wheel drive | 4*4 (4*2) | |||||||
Dimension(L*W*H)mm | 3350*1500*1860 | |||||||
Weight(kg) | 1210-1380 | |||||||
Front wheel tread (mm) | 850,970,1000,1100,1200,1300 adjustable | |||||||
Rear wheel tread (mm) | 970 - 1300 unlimited adjustable | |||||||
Wheel base (mm) | 1750 | |||||||
Min land clearance(mm) | 330(340) | |||||||
Gear shifts | 8F + 2R | |||||||
Tyre size | 9.5-24/650-16 (9.5-24/550-16) | |||||||
Engine Specification | ||||||||
Model | JD/LC/WEICHAI/QC | |||||||
Type | 2 Cylinder or 3 Cylinder | 3 Cylinder | 4 Cylinder | |||||
Type | Water cooled ,vertical,4 stroke and direct injection | |||||||
Rated power(kW) | 13.23 | 16.16 | 18.37 | 20.58 | 22.06 | 25.7 | 29.4 | 33.1 |
Rated revolution (r/min) | 2300/2400 | |||||||
Start way | Electricity start | |||||||
Transmission | (4+1)*2 shifts | |||||||
Clutch | Single chip,dry friction,constant conjunction, single clutch,double clutch | |||||||
PTO speed | 6 Spline, dual speed 540/720 | |||||||
Clutch | Single stage clutch | |||||||
Steering | Hydraulic steering and double hydraulic pumps |
Optional parts:Roll bar,Swing draw bar,Sun-shade ,canopy (ROPS),Spring seat,Multi-way valve,
Double clutch,Fender,750-16/11.2-24 tire,Air brake,Combination instrument,
Steel frame package,Cabin (including the heater and fan).
This series is middle hp tractor, which directly connected with its engine.Jaw type differential lock can
improve the pass-ability.Hydraulic output interface can make direct connection with the dump trailer.
This series tractor can have many different configurations according to customers demands:single stage
clutch or two stage clutch,(4+1)*2 eight shifts in which the creeping shift can be selected,one or two
speed PTO,fixed or adjusted tread,roll bar and canopy,combination meter,heater cabin and so on.
Implements available for this series of tractor.We can supply Front end loader,Backhoe,Pallet fork,
Snow blower,Bulldozer,Posting hole digger,Rotary tiller,Share plow,Disc plow,Disc harrow,Seeder,
Mower, Sprayer,Trailer and so on.
More details,kindly contract me.
1)Firm and safe package to protect the tractors avoiding damage
2)Completed units package or SKD iron frame package in containers
For 1x20ft container, completed packing for 2 unit or SKD steel frame packing 8 units;
For 1x40GP, completed packing for 4 unit or SKD steel frame packing 16 units.
