hydraulic tipper 5 ton trailer axle with best price
- Category: >>>
- Supplier: Jiangxi Gino Vehicle Industry Co. Ltd.
Share on (60739287866):
Product Overview
Description
Gino a professional manufacturer of trailers and trailer parts.
Especially the Popular Single Axle box bolted trailers, Single Axle weld trailers, Tandem bolted trailers, Tandem weld trailers,Hydraulic Tipping trailers(drop down side) ,Hydraulic tipping weld trailers,Camper trailers. Different size can be made
(6*4 7*4 7*5 8*5 9*5 10*5 10*6 12*5 12*6).
winch can be choiced. Can do OEM &ODM trailers or design as customer’s request. Competitive price(factory direct) welcome to visit our factory.
Company Introduction
Product Description
| Hydraulic Tipping Trailers | ||
| Finishing: | Hot dipped galvanized | |
| Load capacity: | 3000KG | |
| Frame steel: | Draw Bar: | 150x50x4mm |
| Chassis: | 100x50x3mm | |
| Cross bar | 70x50x3mm | |
| Sheet steel:(bolted) | 2.5mm checker steel plate floor&1.5mm drop down side walls & Doors | |
Sheet steel: (fully weld) | 2.5mm checker steel plate floor &2.5mm side wall&doors | |
| Tyre: | 215/75R15(8ply,850kgs) with white powder coated 6 studs rims | |
| Axle: | 50x50mm square solid electric brake | |
| Springs: | 7 leaf heavy duty rocker roller springs | |
| Hydraulic System: | 3.5Tonne 4 stage hydraulic ram with 12V, 1.5KW Battery powered hydraulic system | |
| Coupling: | Australian style & 12mm ADR safety chain | |
| Mudguard: | 2.5mm chequer steel plate mudguard | |
| Mesh cage height: | 600mm;900mm,1000mm removable mesh cage | |
| Mesh cage : | 30x30x1.5mm tube | |
| Jockey wheel: | 2000LBS(Double Wheel) &Side swing | |
| Lights&Reflector | LED Taillights with e-mark&DOT certification | |
| Spare tyre: | Non (All trailers do not include the spare wheels) | |
| Tie down: | 20mm round tube tie down all around the trailer | |
As buyer style coupling and safety chain with D-lock: | Yes | |
size
| Hydraulic Tandem Tipping Trailer (Drop Down Side) 3 Tonne,with cage | |||||
| Model No. | Trailer box size | Loading | Tare weight | 20FT | 40FT |
| GN-HTD85C | 2440X1525X450mm | 3000KG | 940KG | 10pcs | 36pcs |
| GN-HTD95C | 2745x1525x450mm | 3000KG | 970KG | 10pcs | 40pcs |
| GN-HTD96C | 2745x1830x450mm | 3000KG | 995KG | 8pcs | 35pcs |
| GN-HTD106C | 3050x1830x450mm | 3000KG | 1025KG | 6pcs | 28pcs |
| GN-HTD126C | 3660x1830x450mm | 3000KG | 1095KG | 6pcs | 24pcs |
| Hydraulic Tipping Tandem Trailer(Fully welded) 3 Tonne | |||||
| Model No. | Trailer box size | Loading | Tare weight | 20FT | 40FT |
| GN-HT85TW | 2440X1525X450mm | 3000KG | 935KG | 10pcs | 40pcs |
| GN-HT95TW | 2745x1525x450mm | 3000KG | 965KG | 10pcs | 36pcs |
| GN-HT96TW | 2745x1830x450mm | 3000KG | 985KG | 8pcs | 34pcs |
| GN-HT106TW | 3050x1800x450mm | 3000KG | 1005KG | 6pcs | 32pcs |
| GN-HT126TW | 3660x1800x450mm | 3000KG | 1085KG | 6pcs | 25pcs |
