full auto plastic blister Forming Filling Sealing Cutting Packaging Machine
- Category: >>>
- Supplier: Shanghai Puxiong Industrial Co. Ltd. [Shanghai China]Shanghai
Share on (60740267922):
Product Overview
Description
full-auto plastic USB blister Forming Cutting Pakcaging Machine
Product Description
Full automatic blister heat sealing machine adopts electron heating,which is especially designed for PVC blister packaging.Meanwhile, machine can be customized for packaging double blisters,sandwich products.The machine is widely applied in hardware,stationary, toys,electron,supplies,cosmic and pills packaging etc,Such as toilet cleaner,glue,eraser, correction tape,lighter,pen,socket,injection,battery,toothbrush lipstick etc.
1.Stable Quality:adopt opposite heating plates,when the machine off,heating plate will open automatically.In case that high temperature will damage the material.
2.Nice Packaging:concave and convex mold can stretch PVC material effectively,formed by blowing can guarantee blister thickness balanced,strong and smooth.
3.Accurate Orientation:Adopt mechanical transmission,servo motor driven.
4.Low Noise,improve the stability of the machine.
5.Safe Operation:Adopt photoelectric control,automatic detection,improve the safety of operation.
6.Reasonable Structure Design:The machine design is separate,which is convenient to move in and out of elevator.
7.Can be customized:Design the mold and material loading method according to the packaged product.
Items | full-auto plastic USB blister Forming Cutting Pakcaging Machine |
Model | PXBP-I03B |
Working Process | PVC sheet loading--PVC heating--blister forming--servo driven--blister cutting--wasted PVC collecting--blister delivering--blister releasing--paper card unload--welding--finished product out |
Packaging Material | Hard PVC ( 0.15-0.5) *370mm |
Air Supply | 0.5-0.8MPA more than 0.5cubic meter/min |
Output Power | 10KW |
Power Supply | 380V,50Hz,3P (domestic),Customized ( foreign ) |
Pressure Mode | Pneumatic ≤0.6MPA (adjustable) |
Mould Cooling Water | Natural water or cycled water 50L/hr |
Production Capacity | 12-25 punches / min |
Stroke Range | 50-160mm |
Max. Paper Card Area | 370*200mm |
Max. Forming Area and Depth | 350*160*35mm |
Overall Dimension ( L W H ) | 3300*2200*1700mm |
Weight | 2000KG |
Related Products
Company Information
Certifications
Exhibition show
Packaging & Shipping
FAQ
1.How to install & run the machine?
The seller offers instruction video,and English version manual will be shipped together with the machine.If necessary,the seller will offer overseas support.
2.What is warranty of the machine?
Warranty is one year,and maintenance is lifelong.The worn-out parts will be sent according to the buyer's condition.While guarantee is not valid if the machine is used in wrong way or it is not maintained as shownin the technical handbook.
3.How to get spare parts?
The seller will enclose some quick wear parts with the machine when buyer places an order.
4.How to guarantee the machine received in a good condition?
QC department of the seller will control the quality from raw material to the finished product.When the machine is finished,the seller will send the buyer inspection video or photos.Or buyer can come to seller’s factory to check it .
