IPTV System Solution with VOD/CMS for Hotel HD 1080P

Number of STB

Server Configuration

Switch

Remarks

300≤

IPTV Server:Dell730

CPU: Xeon E5-2609 v3

Memory:16G

Network: Four-port Gigabit NIC

Storage:configure as needed (suggest 1T above)

1 set

Gigabit

If the UDP protocol is adopted in live services, switches of access layer should support IGMP protocol.

500≤

IPTV Server:Dell730

CPU: Xeon E5-2640 v4

Memory:32G

Network: Four port Gigabit NIC

Storage:configure as needed (suggest 1T above)

1 set

Gigabit

 (1) If the system has high requirements for VOD services and video playback services, like online VOD is with over 300 terminals, it is strongly suggested to configure a storage server.

(2) If the UDP protocol is adopted in Live services, Switches of Access Layer should support IGMP protocol.

IPTV Storage Server:OceanStor S2200T

Cache:16G

Storage:configure as needed

1 set (Optional)

>500

IPTV Server:Dell730

CPU: Xeon E5-2640 v4

Memory:32G

Network: Four port Gigabit NIC

Storage:configure as r needed (suggest 1T above)

1 set

Gigabit Switches and Switches of Access Layer should support  IGMP protocol

If the system has high requirements for VOD services and video playback services, like online VOD is with over 300 terminals, it is strongly suggested to configure a storage server. The specific model should consult storage server supplier.

IPTV Storage Server

Storage:configure as needed

1 set (Optional)
