WODE 36 Volt 0.28A Constant Current Waterproof Dimmable Led Driver
- Category: >>>
- Supplier: Yueqing Wode Electrical Co. Ltd.
Share on (60742379104):
Product Overview
Description
Product Description
WODE 36 Volt 0.28A Constant Current Waterproof Dimmable Led Driver
♦ Features
1) High Efficiency And Good Price
2) Built-in EMI Filter
3) 100% Full Load Burn-in Test
4) Low Output Ripple And Noise
5) Protection:Over Load / Over Voltage / Short Circuit
6) Most items could provide adjustable +-10% for output voltage
7) Could meet the demand perfectly both for 220V and 110V input voltage
8) Could provide customized power supply for special output / special input / special protection etc.
*** Please note: We maybe modify the products according to different situation without informing.
MODEL | BG-10-5 | BG-10-12 | BG-10-24 | BG-10-36 | BG-10-48 | |
OUTPUT | DC voltage | 5V | 12V | 24V | 36V | 48V |
Rated current | 2A | 0.83A | 0.42A | 0.28A | 0.21A | |
Ripple and noise | 100mVp-p | 100mVp-p | 100mVp-p | 100mVp-p | 100mVp-p | |
Intet stability | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
Load stability | ±1% | ±1% | ±1% | ±0.5% | ±0.5% | |
Efficiency | 78% | 81% | 83% | 84% | 85% | |
INPUT | AC voltage range | AC85~265V wide range 47~63Hz | ||||
AC Inrush current | Cold-start current 30A/250V | |||||
PROTECTION | Overload | Protection type : Constant current limiting, recovers automatically after fault condition is removed | ||||
Over voltage | 121%~142% Rated output voltage | |||||
Short circuit | Protection type: shut off | |||||
ENVIRONMENT | Setup,rise,hold up time | 100ms 60ms /230VAC at full load | ||||
Withstand voltage | Input and output internal:1.5KvAc,input and enclosure:1.5KvAc,Output and enclosure:0.5KvAc | |||||
Isolation resistance | Input and output internal:Input and enclosure,Output and enclosure:500VDC/100MΩ | |||||
Working temperature and humidity | -10°C ~+50°C | |||||
Store temperature and humidity | -20~+85°C, 10~95%RH | |||||
OTHER | Overall dimension | 116×29×20mm 126pcs/Carton ( common packing ) | ||||
Weight | 0.12KG | |||||
CERTIFICATE | CE EMC Authenticate | EN55022:2010 EN61000-3-2:2006+AL:2009 EN61000-3-3:2008 | ||||
EN55024:2010 EN55015:2006+AL2007+2009 EN61547:2009 | ||||||
CE LVD Authenticate | EN61347-1:2008T A1:2001 EN61347-2-13:2006 | |||||
EN60950-1:2006+A11:2009+A1:2010+A12:2001 | ||||||
ROHS Authenticate | EPA3050B:1996 EN1122B:2001 EPA3052:1996 EPA3060A:1996 | |||||
EPA7196A:1992 EPA3540C:1996 EPA8270D:2007 IEC62321:2008 | ||||||
Company Information
Wode Electrical Co.,Ltd. was established in 2005 as a professional Power Supply manufacture.Our products cover the following series: Switching Power Supply, water proof IP67 Led driver ,AC/DC converter.These products are widely usde in the fields of LED strip,CCTV system,CNC machine,Outdoors power supply,PLC control system, Interruption accident etc.
