1000W 5V 200 AMP Voltage Stabilizer Power Supply
- Category: >>>
- Supplier: Beijing Jingyi Daming Electronic Technology Co. Ltd.
Share on (60743176992):
Product Overview
Description
1000W 5V 200 AMP Voltage Stabilizer Power Supply
Product Description
Parameter:
Product Name | 1KW DC regulated power supply |
Items No. | WT2C-DC 5200 |
Brand | Yochain |
Type | CNC intelligence power supply |
Input Voltage | 1 phase 210VAC to230VAC |
OutputPower | 1KW |
OutputCurrent | 200A |
Output Voltage | 5V |
Waveform | Positive polarity direct current |
Work mode | Regulated power supply |
Regulation Precision | ≤1% |
Efficiency | ≥90% |
Power Factor | cosΦ≥0.9 |
Power Switch | DB9 pin |
Control Mode | 1)Analog signal control: TTL potential 2)Digital interface control can be custoimized: RS-485 /RS-232 |
Insulation Class | B |
Protect Grade | IP20 |
Protection Response Time | 1uS |
InputShell Resistance | ≥20MΩ |
OutputShell Resistance | ≥20MΩ |
InputWithstand Voltage | 2000V/1min |
OutputWithstand Voltage | 3500V/1min |
Temperature | 0~35℃ |
Humidity | ≤85% |
Cooling mode | Air-cooling |
Dimensions | 320*130*95(mm) |
Installation Dimension | 191*110(mm) |
Note | 1)Output current voltage can be customized 2)Factory default analog interface |
Name: 1KW DC power supply
Model: WT2C-DC 1KW series
Model Information: WT2C-DC XXXYYY
WT2C—Yochain 1KW
DC—Directly current
XXX: max output voltage: 3 digits or 1 digits, Unit: V
YYY: max output current: 3 digits or 1 digits, Unit: A
Specification
Specification
Model | Output Power | Output Voltage | Output Current |
WT2C-DC 10001 | 1000W | 1000V | 1A |
WT2C-DC 5002 | 1000W | 500V | 2A |
WT2C-DC 4002.5 | 1000W | 400V | 2.5A |
WT2C-DC 2504 | 1000W | 250V | 4A |
WT2C-DC 2005 | 1000W | 200V | 5A |
WT2C-DC 10010 | 1000W | 100V | 10A |
WT2C-DC 5020 | 1000W | 50V | 20A |
WT2C-DC 4025 | 1000W | 40V | 25A |
WT2C-DC 2540 | 1000W | 25V | 40A |
WT2C-DC 2050 | 1000W | 20V | 50A |
WT2C-DC 10100 | 1000W | 10V | 100A |
WT2C-DC 5200 | 1000W | 5V | 200A |
Product Overviews
Packaging & Shipping
1. PAYMENT: Bank Transfer, Paypal, T/T, Wester Union etc. acceptabel.
2. SHIPMENT: Sea, Air, Express(DHL, EMS, FedEx, HongKong Post, UPS, Swiss Post, TNT etc.)
3. PACKAGE: Cartons
FAQ
1. What is the minimum order quantity (MOQ) for products?
Generally according to the requirements of customers, no matter how many we can accept.
2. How long is the product warranty?
We guarantee 1 year for our customers but they bear the freight fee or repair some accessories for secondary purchase.
3. What's the advantage of your products?
More than 10 years of experience in production and sales, with independent brand complete variety of products of repair industry.
4. Are you accept OEM order?
Yes, of course, please feel free to contact our staff for details.
5. What about delivery day?
For sample with existing products, delivery within 3 days; and for customation products in great quantity, 7 to 15 days. Generally 20-30 days for customer OEM products.
