A60 A65 A70 A80 High speed home use LED PC / PET / PP bulb led light Lamp Cover Making Machine in plastic blowing machines

Product Overview

Description

A60 A65 A70 A80 High speed home use LED PC / PET / PP bulb led light Lamp Cover Making Machine in plastic blowing machines

Product Name:   Led Light PC Bulb stretch Blow Moulding Machine Price

PC Lamp Cover Blow Molding Machine

Model No. : KM-S200P-2-CAVITY

 Place of Origin: Taizhou, China

 Trademark:  KEMO

 Delivery Date:  20days

 Productivity: 30 Sets/Month

 Packing: Wooden Case or film

 Function: For Producing Pet Bottles

 Payment Type: T/T or L/C

 Certificates: SGS, CE, ISO9001

 Export Markets: All of the World

 KM Machinery, the Professional blow moulding machine supplier in China.



Summary

PC Lamp Cover Blow Molding Machine, for various kinds of the Led lamp cover, manual feeding, automatic dropping. With the advantage of save cost, easy operate, safe and so on.



Feature

1. High safety factor:  avoid the danger of semi machine to take the bottle by hand, improved the production efficiency.

2. Saving work: many single operation or sevral machine work at the same time, saving labor for 2 to 3 times than the semi machine.

3. Stable performance: Adopt the imported touch-screen computer interface, precise, fast and strong stability. Simple structure, oven adopt the chute type integration, easy maintenance.

4. The detecting element use the Japanese Omron electronics, high voltage control choose the imported famous quality products, with reliable performance and accurate response.

5. Adopt the infrared lamp heating, strong penetrating power and uniform heating, the width and the height of the baffle-board can be adjusted, to fit the bottle preform heating of different structure.

6. With the function of  automatic alarm, and self-check of the fault detection and judgment..

7. Imported from Germany, Japan, Taiwan, pneumatic components, to ensure high speed run zero failure rate.

8. The gas circuit design and the blow is divided into two parts, in order to satisfy the demands of bottle blowing and action of different pressure, to achieve the high pressure blowing products. Also if choose and buy high pressure bottle blowing exhaust gas recycling system, can save 10-15% of the air.

9. Adopt hyperbolic cubits, with strong clamping force of the main link hinge, have C-mold pressurization function when blowing bottle in high pressure, stable and reliable.

10. Moving parts adopt high speed linear guide, with advantage of high wear resistance, opening and closing mould high speed running fast without trembling, etc.









  Technical Parameter :

ITEM	KM-S200P
Theoretical output	1800
Max.container volume	2L
Max.neck diameter	45MM
Max.container diameter	120MM
Max.container height	325MM
Number of cavity	2
Number of lamp	24
Max.heating power	35KW
Installation power	30KW
Actual power consumption	12KW
Operating low pressure	0.7-1.0Mpa
Low pressure consuming	1800L/min
Blowing pressure	2.0-3.0Mpa
High pressure consuming	2500L/min
Operating pressure	0.3-0.5Mpa
Temperature	16 degree
Flow rater	30 L/min
Machine dimension	2.0×1.6×1.8
Machine weight	1800Kg

    (Note: for reference only, it is based on the actual work.)



Mould

KEMO Use CAD-CAM design mould, completely anticorrosive processing, process by high precision CNC machine, to achieve accurate, smooth lines capacity, the size and the design is the same as original. We also provide the free design of the mould drawing.
