hanging fogger system air circulation ventilation fan one direct design

Centrifugal humidifier works

Under the action of a rotating disc rotating at a high speed, due to the friction between the water and the rotating disc, the water will make an increasingly large-scale circular motion, and the water will rapidly go out along the tangential direction of the outer edge of the disc. When the water collides with a solid obstacle, it will produce extremely small droplets, thus increasing the evaporation surface area; the mist droplets are blown by a powerful fan, which increases the wind speed on the surface of the liquid and accelerates the diffusion of gas molecules, thus greatly evaporating the water. Increase, the water absorbs heat in the evaporation process, reduces the temperature, can increase the relative humidity of the air at the same time, reduce the dust, purify the air; This kind of spray fan uses the principle of the centrifugal motion of the object, so call it the centrifugal spray fan.

Centrifugal humidifier working characteristics

1, humidification speed. Can be suspended, wall-mounted, manual and other free to set up the installation, does not occupy the work site, flexible and convenient, safe and reliable.

· Micro-particles (5 to 10 μm) are sprayed and no wet spots of water droplets are generated.

2. It is especially suitable for the direct humidification of the working environment where the humidity standard is high (>60%RH) or the heat source is difficult to humidify.

· Suitable for both small refrigerators and large industrial environments, and can be used directly for humidification of central air conditioners.

3, a large range of humidification, between 3kg/h ~ 48kg/h.

·Can be automatically controlled

4, humidification, no special requirements on water quality.

Centrifugal humidifier adaptation scope

1. Suitable for cotton spinning, wool spinning, weaving, silk, clothing, knitting, chemical fiber, printing, cigarette, hemp products, flowers and other places that need to adjust humidity, can also be used as a desuperheater or exhaust fan.

 Fourth, centrifugal humidifier conditions of use

The main voltage - If the main voltage fluctuates, it should be within ± 10% of the voltage specified on the nameplate.

Ambient temperature-The temperature in the room should be within the range of -10°C to 35°C.

Ambient humidity-The maximum relative humidity allowed in the room is 95%, but condensation water is generated.

Packing Details  : Packing,use the best carton

Delivery Details :7 days after order
