Product Overview

Description


Description
\t
SIZE CODE （mm)
\t
A
\t
B
\t
C
\t
A2 T 5*2.5*3
\t
5.0±0.50
\t
2.5±0.40
\t
3.0±0.40
Parameter
\t
Electrical Requirements
\t
SIZE CODE （mm)
\t
A2 T 5*2.5*3
\t
25 MHz
\t
16Ω MIN
\t
100 MHz
\t
54Ω MIN
\t
TEST INSTRUMENTS
\t
HP 4191A
\t
LCR METER
\t
HP 4286
\t
WIRE
\t
0.65T.C.W*100m/m 1/2Ts
\t
TEMPERATURE
\t
15℃ to 35℃
\t
HUMIDITY
\t
25% to 85% RH
\t
Test Data For Pre Production Samples
\t
MEAS.
 Item
\t
Ω
 AT 25MHz
\t
Ω
 AT 100MHz
\t
A
 m/m
\t
B
 m/m
\t
C
 m/m
\t
Suggest
\t
16Ω MIN
\t
54Ω MIN
\t
5.0±0.50
\t
2.5±0.40
\t
3.0±0.40
\t
1
\t
19.56
\t
66.85
\t
5.01
\t
2.69
\t
3.10
\t
2
\t
19.85
\t
67.85
\t
5.00
\t
2.68
\t
3.12
\t
3
\t
19.65
\t
67.15
\t
5.01
\t
2.65
\t
3.14
\t
4
\t
19.04
\t
65.84
\t
5.03
\t
2.66
\t
3.11
\t
5
\t
19.81
\t
66.12
\t
5.05
\t
2.71
\t
3.12
\t
6
\t
19.23
\t
67.15
\t
4.98
\t
2.70
\t
3.15
\t
7
\t
19.54
\t
67.15
\t
5.02
\t
2.69
\t
3.13
\t
8
\t
19.81
\t
65.18
\t
5.03
\t
2.69
\t
3.14
\t
9
\t
19.83
\t
68.15
\t
5.01
\t
2.70
\t
3.15
\t
10
\t
19.56
\t
67.45
\t
5.03
\t
2.71
\t
3.12
\t

\t

\t

\t

\t

\t

\t
X-bar
\t
19.59
\t
66.89
\t
5.02
\t
2.69
\t
3.13
\t
R
\t
0.81
\t
2.97
\t
0.07
\t
0.06
\t
0.05
\t
The above test data for reference，Actual results may differ due to different production batches
