MODEL

BG-120-5

BG-120-12

BG-120-24

BG-120-36

BG-120-48

OUTPUT

DC output voltage

5V

12V

24V

36V

48V

Rated output current

24A

10A

5A

3.33A

2.5A

Wave and noise

100mVp-p

100mVp-p

100mVp-p

100mVp-p

100mVp-p

Intet stability

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

Load stability

±1%

±1%

±0.5%

±0.5%

±0.5%

Efficiency

80%

81%

83%

83%

83%

INPUT

AC voltage range

AC85~265V wide range 47~63Hz

AC inrush current

Cold-start current 30A/250V

PROTECTION

Overload

Protection type : Constant current limiting, recovers automatically after fault condition is removed

Over voltage

121%~142% Rated output voltage

Short circuit

Protection type: shut off

ENVIRONMENT

Setup rise hold up time

100ms 60ms/230VAC at full load

Withstand voltage

Input and output internal:1.5KvAc,input and enclosure:1.5KvAc,Output and enclosure:0.5KvAc

Isolation resistance

Input and output internal:Input and enclosure,Output and enclosure:500VDC/100MΩ

Working temperature and humidity

-10~+50°C

Store temperature and humidity

-20~+85°C, 10~95%RH

OTHER

Overall dimension

189*49*34mm   24pcs/Carton ( common packing )

Weight

0.88KG

CERTIFICATE

CE EMC Authenticate

EN55022:2010 EN61000-3-2:2006+AL:2009 EN61000-3-3:2008

EN55024:2010 EN55015:2006+AL2007+2009 EN61547:2009

EMC CE LVD Authenticate

EN61347-1:2008T A1:2001 EN61347-2-13:2006

EN60950-1:2006+A11:2009+A1:2010+A12:2001

ROHS Authenticate

EPA3050B:1996 EN1122B:2001 EPA3052:1996 EPA3060A:1996

EPA7196A:1992 EPA3540C:1996 EPA8270D:2007 IEC62321:2008
