Мини 1Wan 1Lan 300 Мбит/с OpenVPN беспроводной маршрутизатор Qualcomm QCA9531 openwrt wifi маршрутизатор с USB портом
Мини 1Wan 1Lan 300 Мбит/с OpenVPN беспроводной маршрутизатор Qualcomm QCA9531 openwrt wifi маршрутизатор с USB портом
Мини 1Wan 1Lan 300 Мбит/с OpenVPN беспроводной маршрутизатор Qualcomm QCA9531 openwrt wifi маршрутизатор с USB портом
Мини 1Wan 1Lan 300 Мбит/с OpenVPN беспроводной маршрутизатор Qualcomm QCA9531 openwrt wifi маршрутизатор с USB портом
Мини 1Wan 1Lan 300 Мбит/с OpenVPN беспроводной маршрутизатор Qualcomm QCA9531 openwrt wifi маршрутизатор с USB портом
Мини 1Wan 1Lan 300 Мбит/с OpenVPN беспроводной маршрутизатор Qualcomm QCA9531 openwrt wifi маршрутизатор с USB портом

Мини 1Wan 1Lan 300 Мбит/с OpenVPN беспроводной маршрутизатор Qualcomm QCA9531 openwrt wifi маршрутизатор с USB портом

Share on (60746831469):


Price:12,50 $ - 14,50 $

Quantity:


Product Overview

Description


Product Description

Overview:


HL-WR840 is using QCA9531 solution. The main frequency is up to 650MHz. It supports 1* 10/100M WAN + 1*10/100M LAN. 2.4GHz is 300Mbps.  It complies with the IEEE802.11b/g/n wireless network protocol. It has two Built-in 5dBi antennas. The coverage area is more than 50 meters and t supports about 30 access points.


Specification:
* Complies with EEE802.11b/g/n protocol
* Provides 1* 10/100M WAN+1*10/100M LAN+1USB Port
* Supports Reset function
* Supports Uboot brush
* Supports 64/128 bit WEP encryption, WPA/WPA2, SPA-PSK/WPA2-PSK and other encryption and security mechanism
* The wireless standby number is 30, HD video is 4~5, wired is about 80.


\t
Hardware Features
\t
Chipset
\t
QCA9531/650Mhz
\t
FLASH
\t
SPI 8MB
\t
RAM
\t
DDR2 64MB
\t
Protocol
\t
IEEE802.11n/802.11g/802.11b/802.3/802.3u
\t
Transmit Power
\t
802.11b 18dBm±2dBm
802.11g 15dBm±2dBm
802.11n 15dBm±2dBm
\t
Reception Sensitivity
\t
802.11b: -83dBm@10% PER
802.11g: -74dBm@10% PER
802.11n: -68dBm@10% PER
\t
Wireless Speed
\t
Max 300Mbps
\t
Working Frequency
\t
2.4GHz (2T2R)
\t
Antenna Type
\t
2 Built-in 5dBi antenna
\t
Interface



\t
1 *10/100M WAN port (Auto MDI/MDIX)
1 *10/100M LAN port (Auto MDI/MDIX)
1 * USB port
\t
LED
\t
Power
\t
Button
\t
Reset
\t
Power Supply
\t
micro usb 5V2A
\t
Max power consumption
\t
< 12W
\t
Dimensions(L*W*H)
\t
65*46*20MM
\t
Software
\t
\t
Default Setting
\t
IP Address: 192.168.1.1
User/Password: admin/admin
\t
WAN Type
\t
PPPoE/ Dynamic IP/Static IP
\t
Working mode
\t
AP;Router
\t
System
\t
Supports SDK，OpenWRT,　eCos
\t
DDNS
\t
Support
\t
WEB Style Change
\t
Support
\t
Band Ctrl
\t
Support
\t
Static Router
\t
Support
\t
System Log
\t
Support
\t
DHCP server
\t
DHCP server
Client List；
Static address assignment；
\t
Virtual Server
\t
Port Forwarding
DMZ
\t
Security
\t
Client List Filter
MAC Address Filter
URL Filter
Remote WEB management
\t
Others
\t
Mac address clone
Configuration file import and export
Web upgrade
\t
Others
\t
\t
Package Contents
\t
Wireless router
2*5dBi antennas
Power supply
Kraft paper box (100*100*50mm)
\t
Bare Weight
\t
0.08kg
\t
Total Weight
\t
0.15kg
\t
Adapter
\t
NO
\t
Work Environments
\t
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
