XJ 01 Handheld mini Wireless Sonar Sensor Fish Finder for fishing enthusiast or fisherman

Product Overview

Description

XJ-01  LED Display handheld Wireless Sonar Fish Finder



Specification:

1. Display

    Display: Dot Matrix LCD

   Display Size: 50x45mm

   DisplayDot Number: 128*96

   DisplayContrast: 10~100%

   Backlight: White LED Backlight



2. Sonar & Radio

    Depth Range: 2-120Ft/0.6-45M

    Wireless Operating Range : 100m

    Sonar Frequency: 125KHZ

    Sonar Beam Angle: 90 degree

    Radio Frequency: 433.92 MHz

    Operational Temperature: -20 ~70℃



 3. Power Supply:

  Mainframe : Lithium battery  3.7V

  Transducer: Polymer battery  3.7V



This fish finder is designed for amateur and professional fishermen and fishing enthusiast to find out the fish location (either in groups or not) in any particular area and to determine the depth of the water. With the latest advanced sonar detection technology it can display live update of the water bottom contour. It also detects and displays grasses, sands and rocks on seabed. This amazing product can be used in both fresh water and salt water such as ocean, river, lake, etc. and even on ice or icy water.
