Product Overview
Description
CMX/CM/CMR/CMP Certified Cat7 Cat5e Cat6 Ethernet Cables
CMP certified cat5e cable :
BC conductor unshield, 4pairs Standard: TIA/EIA568B, YD/T1019-2001
4*2*0.57mm pure copper, PE insulation 1.02mm+ rip code+ PVC jacket, option color
Conductor:
Material: solid bare copper
Number of pairs: 4 pairs
AWG:23awg, 24awg,26awg,28awg
Conductor diameter: 0.57±0.01mm
Insualtion:
Material: HDPE and FRPE
Diameter: 0.944±0.005mm
Average thickness: 0.212mm
Minimum point thickness: 0.2095mm
FILLING: petrolatum or without jelly filled
Sheath:
Material: HDPE
Nominal diameter: 5.8±0.2mm
Average thickness: 1mm
Minimum point thickness: 0.9mm
Operating temperature range: -20 to 75°C
Minimum bend radius (install): 8xOD
Flame test: CMR, CM, IEC60332-1
Reference standard: TIA/EIA568B, IEC/ISO11801
Applications:
Computer Network Cabling Project.
Broadband Network Communication.
Digital ISDN Network and ATM 155Mbps Network
Ethernet Network
Audio and Data Transmission
1. Q: Is Lucktech a manufacturer or trading company?
Lucktech has its own invested factory, and also do some trading for the items we do not produce. We are competitive even for the trading items, as we have a strong sourcing team who concern about quality.
2. Q: What's the normal lead time?
For different items, we have different lead time, normally it is 15-35 days.
3. Q: Can We get samples for your products?
Yes, samples are available, but for some items, sample cost need to be charged, which can be returned after your formal order.
4. Q: DO you have CPR compliance for the cables?
Yes, now we get through the CPR Testing.
5. Q: What is your payment terms?
T/T, sight L/C, Western Union, Paypal
6. Q: Do you have the OEM service?
Yes, we can accept the OEM, any legal information can be printed on the product.
