China Supplier PROUD EAGLE Brushless DC Motor Controller
Product Parameters
Maximum Ratings & Main parameters | |
Rated voltage | 48V/60V/72V DC |
Max battery current | 45A |
Rated output power | 1200W |
Operating temperature range | -20℃~100℃ |
Storage temperature range | -55℃~85℃ |
Motor control mode | FOC(Field oriented control) |
Standby power consumption | 20~40mA |
Max motor speed limitation | Depended on motor and configuration |
Driving method | Direct torque control |
Product Description
It’s designed with FOC(Field Oriented Control)algorithm in which SVPWM is used to drive the powerdevice so that it injects sinusoidal current to the three-phaseof motor. Controller can achieves maximum torque control, constant powercontrol, speed closed loop control and energy feedbackcontrol while braking. Pure sine wave/Regen Brake/Parametres can be adjustable.
