PP Pipe Belling Machine(fast machine)

Pipe

standards

Model

DS160PP-NI

standard

PP and PVC pipes

Diameter

40mm - 160mm

Length

3m - 6m

Heating

Oven

2 heating stations, Contact heating by Aluminum block，Stainless steel heating tube, with internal heating

Pipe Rotary

Clockwise and anti-clockwise

Thermocouple

K-type

Temperature controller

Omron

Heating Power

25KW

Electrical component

PLC and Screen

Siemens

low-voltage apparatus

Schneider, Omron

Total Power

30KW

Use voltage

380V, 50HZ, 3-phase  (as request)

Wire dimension

Pneumatic

Compressed air pressure

0.6Mpa   230l/min  10mm

Pneumatic valve

SNS

Water

Water pressure

0.4Mpa   155l/min  10mm

Hydraulic

Hydraulic pressure

6.3Mpa

Hydraulic oil

LHM-46, about 50 litre

Solenoid valve

Taiwan Ashun

Oil pump motor power

3KW

Equipment

appearance

Machine type

Automatic, single line, one pipe per cycle

Center height

1000mm  (as request)

Height adjustment

Eletrical - via button

Machine color

Frame：Light grey RAL7032，Cover plate：Blue

(as request)

Machine dimension

5600mm(L)×2250mm(W)×2100mm(H)    1*40GP

Machine weight

4500kg

Operating principle

J-type

Blow air by inner mould, and take shape by outer mould

Cooling type

Water air - cooling

Machine speed

50S to 150S

Mould material

J-type：45# steel with Cr electroplating
