Characteristic: ABS Materials; Authentic Electron Conponents;High Quality and Stability
Description:
1. Up and down optical lens can adjust the mechanical design, making adjustments more faster, convenient and accurate.
2. Ten signal design, horizontal / vertical optical angle adjustment is convenient, easy to calibrate
3. Artificial Intelligence recognition technology, digital conversion and superior signal filtering
4. With high levels of anti-RFI / EMI capability
5. Unique design of the digital filter circuit
6. High-power transmitter, sensitivity surplus degree up to 90%
7. Anti-lightning circuit design
8. With rain cover design
9. C relay output
10. Adjustable of beam interdiction period, to make it more flexible and adaptable
11. Professional anti-jamming optical housing
12. High-power infrared receiver tube, low-power process technology
Parameters:
Model
UM-DS20
UM-DS30
UM-DS40
UM-DS60
UM-DS80
UM-DS100
Outdoor Alert Distance
20M
30M
40M
60M
80M
100M
Indoor Alert Distance
60M
90M
120M
180M
240M
300M
Beam No.
2
Induction Speed
50-700ms
Alarm Output
NC&NO contact rating:AV/DC 30V/0.5mA
Ganged Alarm
Yes
Working Voltage
DC13.8-24V AC 11-18V
Working current
40mA
40mA
55mA
55mA
65mA
65mA
Longlife mode
20mA
20mA
30mA
30mA
35mA
35mA
Humidity
5%-95%(RH)
Tamper output
NC&NO contact rating:AV/DC 24V/0.5mA
Horizontal angle adjustment
180°±90°
Vertical angle adjustment
±10°
Dimensions
17*8*7.5cm
PCS/CTN
20PCS/CARTON
Packing dimensions
49.5*45*36cm
Detailed Images
