Item# CES100 Oscillating Horizontal Wood Belt Sander | ||||||||
The CES80 is the 6" x 99" Oscillating Edge Sander which focus on versatility, accuracy and durability you need, in one exceptionally well designed machine. The cast iron table moves vertically allowing for the workpiece to be positioned at a precise height. The outer table adjusts for contour sanding. The 4'' dust port makes dust removal easy and oscillation reduces heat increasing, loading and burning. Edge, face, bevel, and contour sanding are all on one machine - with the power for big jobs and control for fine work. | ||||||||
Features
* Oscillating feature reduces heat build-up on sanding belt to reduce loading and burning which increases belt life
* Precision ground cast iron table with miter slot
* Adjustable outer table enables contour sanding
* Quick release lever and tracking control dial are conveniently located for replacing and tracking belts
* Belt platen is made from precision-ground steel plate for strength and durability
* Graphite covered platen runs cooler increasing machine and belt life
* Cast iron table moves up or down to provide exact workpiece positioning
* 4" dust port hooks up to your dust collection system for efficient dust removal
* Tilting sanding head for sanding bevels, angles and flat surfaces
* Big side fence provides accurate support for small workpiece sanding
* Stand with storage
* Precision ground cast iron table with miter slot
* Adjustable outer table enables contour sanding
* Quick release lever and tracking control dial are conveniently located for replacing and tracking belts
* Belt platen is made from precision-ground steel plate for strength and durability
* Graphite covered platen runs cooler increasing machine and belt life
* Cast iron table moves up or down to provide exact workpiece positioning
* 4" dust port hooks up to your dust collection system for efficient dust removal
* Tilting sanding head for sanding bevels, angles and flat surfaces
* Big side fence provides accurate support for small workpiece sanding
* Stand with storage
Details Images
Specification | ||||||||
Motor | 220v/1ph/2.2kw | |||||||
Worktable size | 845mm x300mm (33-1/4" x12") | |||||||
Outer table size | 300mm x250mm (12"x10") | |||||||
Sanding belt size | 2512mm x152mm (99"x6") | |||||||
Belt speed | 960m/min | |||||||
Fence size | 700mm x60mm (27-1/2"x2-3/8") | |||||||
Belt tilting | 0~90° | |||||||
Dust port dia | 100mm (4") | |||||||
Overall size | 1500mm x620mm x1300mm (59" x24-1/2"x51") | |||||||
Unload noise | 80 dBA | |||||||
Net weight | 135kgs | |||||||
Gross weight | 168kgs | |||||||
Packing dimensions | 1350mm x820mm x1150mm | |||||||
