Product Overview
Description
60 CFM Oil-Water Separator | Ingersoll Rand PSG-7
- Air System Design Capacity: 60 CFM
- Maximum Water Capacity: 1.0 Gal / 3.8 L
- Maximum Water Flow: 0.55 Gal-Hr / 1.9 L-Hr
- Maximum Absorbed Lubricant: 3 Lbs / 1.4 Kgs
- Inlet Pressure Range: 0-175 PSIG
- Dimensions: 21″ L x 11.5″ Diameter
- Connection Size: 1/2″ NPT (Inlet / Outlet)
- Shipping Weight: 11 Lbs (Approx)
- High Efficiency Oil-Water Separator System
- Replacement Module Part # 38457008
- * 1-YEAR Full Warranty & Protection Program
390 CFM Oil-Water Separator | Ingersoll Rand PSG-30
- Air System Design Capacity: 390 CFM
- Maximum Water Capacity: 30.0 Gal / 113.6 L
- Maximum Water Flow: 6.9 Gal-Hr / 23.5 L-Hr
- Maximum Absorbed Lubricant: 21 Lbs / 9.5 Kgs
- Inlet Pressure Range: 0-175 PSIG
- Dimensions: 21″ L x 34″ W x 39″ H
- Connection Size: 1/2″ NPT Inlet / 3/4″ NPT Outlet
- Shipping Weight: 105 Lbs
- High Efficiency Oil-Water Separator System
- Replacement Module Part # 38465712
175 CFM Oil-Water Separator | Ingersoll Rand PSG-15
PolySep PSG Series Oil Water Separator
The key to the PolySep Oil Water Separators’ unrivaled performance is our unique, specially coated Zeolite adsorption media. This proprietary filtration media effectively separates and permanently adsorbs virtually all lubricants, including highly emulsified lubricants like Polyglycol, the most difficult lubricants to separate. Competitive systems simply can’t handle polyglycols without requiring expensive, oversized separators. From mineral oils, PAOs and polyolesters to diesters and Polyglycol, the PolySep Oil Water Separator provides the broadest range of performance and efficiency.
The key to the PolySep Oil Water Separators’ unrivaled performance is our unique, specially coated Zeolite adsorption media. This proprietary filtration media effectively separates and permanently adsorbs virtually all lubricants, including highly emulsified lubricants like Polyglycol, the most difficult lubricants to separate. Competitive systems simply can’t handle polyglycols without requiring expensive, oversized separators. From mineral oils, PAOs and polyolesters to diesters and Polyglycol, the PolySep Oil Water Separator provides the broadest range of performance and efficiency.
PERFORMANCE & DIMENSIONS
- Air System Design Capacity: 175 CFM
- Maximum Water Capacity: 15.0 Gal / 3.8 L
- Maximum Water Flow: 3.1 Gal-Hr / 11.7 L-Hr
- Maximum Absorbed Lubricant: 11 Lbs / 5 Kgs
- Inlet Pressure Range: 0-175 PSIG
- Dimensions: 19″ L x 26.5″ W x 30″ H
- Connection Size: 1/2″ NPT Inlet / 3/4″ NPT Outlet
- Shipping Weight: 54 Lbs
- High Efficiency Oil-Water Separator System
- Replacement Module Part # 38339057
- * 1-YEAR Full Warranty & Protection Program
INDUSTRY APPROVED – CONDENSATE COLLECTION SYSTEMS FOR EVERY APPLICATION
Staying Clean by Going Green Compressor systems produce large amounts of condensate. This condensate contains lubricant contaminants that should be disposed of properly. Ingersoll Rand PolySep Oil Water Separators can help your company be strong stewards of the environment while reducing your annual waste removal costs. When properly installed and sized correctly, the PolySep separators are capable of providing condensate discharge levels as low as 15 mg/l. Our separators feature non-corrosive materials and do not require electrical power for operation, further reducing environmental burdens. You can count on PolySep Oil Water Separators to get you… and keep you…green.
Case, Air compressor+air dryer+inline filter+air tank/ Ingersoll Rand air solution system/compressed air supply system
Air Compressor Dryers and Filters - Ingersoll Rand/air treatment/air solution/oil-water separator filter dryer tank
Dessicant air dryer system/adsorption dryer station/Ingersoll Rand modular air dryer supply
Wrapping up an new installation WITH Ingersoll Rand Simplair Piping. Clean extruded aluminium pipe with pressure ratings up to 225 PSIG. Note the metal fittings as opposed to competitors plastic fittings. Less labor, clean look outside, clean air inside.
R110i 150hp rotary screw air compressor/ingersoll rand lubricated compressor with oil inject/ soft start
installing a new Ingersoll Rand R90ie 125HP Premium Efficiency Two-Stage Rotary Screw Air Compressor today at a gas fired power plant
R110i Compressed air compliance with AIRFLOW regulations is key and ASPS engineers can assist your plant meet and exceed those requirements with certified testing
Contracting Services
Installations
Ingersoll Rand Air Solutions Group now offers a complete range of services in compressed air system installation and integration. From the smallest air-cooled reciprocating air system to the largest water-cooled centrifugal installation, Ingersoll Rand has the capability to manage and implement a complete compressed air system.
Benefits include
- Fully Integrated Project Management
- Single Source Responsibility
- Air System Design
- Fully Integrated Support
- Compressed Air System Expertise
- Air System Optimization
Compressed Air Expertise – Ingersoll Rand’s 100 plus years as the leader in the compressed air business, allows you to benefit from our experience. Ingersoll Rand knows how to design, install, and maintain compressed air systems. Ingersoll Rand’s knowledge of compressed air systems allows them to offer central control sequencing, and monitoring systems.
Single Source Responsibility – Ingersoll Rand can design the compressed air system, supply the compressed air equipment and install the completed system. This allows you to have only one contact to satisfy all your compressed air needs. Ingersoll Rand’s breadth of services allows us to accept complete responsibility and insure your satisfaction.
Air System Design – The proper initial design of the compressed air system will result in superior compressed air system operation. Ingersoll Rand can offer air system design that will meet your present needs and offer flexibility for future expansions. We specialize in multiple types of air compression technologies, and are skilled in selecting the proper equipment design and layout for your operation.
Fully Integrated Project Management – Ingersoll Rand’s Air Solution Group has the ability to handle any type of compressed air system installation. A Project Manager oversees and instructs the complete project, ensuring proper installation and efficient operation.
Fully Integrated Support – Ingersoll Rand is able to supply all necessary support for your air system. We can design, supply, install, repair, and maintain your system. We supply parts and service for all makes and models of air compressors and accessories. With our AirCare compressor maintenance inspection program, extended warranties are available to protect your investment.
Air System Optimization – The ability to optimize a compressed air system comes from years of being in the business. Ingersoll Rand can optimize your system to save you energy costs, reduce maintenance and provide a reliable air system. Optimization involves ensuring that each piece of equipment in the air system is working at properly and each component is tuned to work efficiently with all the parts of the system.
For your compressed air system, Ingersoll Rand is your single source provider, with:
Design service - determine system requirements, equipment selection, and air system layout.
Equipment provider - compressors, dryers, cooling towers, receiver tanks
Project management - equipment, building, piping, complete installation and commissioning
- Maintenance and operation services - long term source for parts and maintenance
IRN55K-OF IRN75K-OF IRN90K-OF
Ingersoll Rand Rotary Screw Air Compressor Nirvana Variable-Speed Drive Oil Free Compressor
Ingersoll Rand Air Compressors and Services
Oil-Free Rotary Screw Air Compressors
Oil-Free Rotary Screw Air Compressors
Nirvana Variable Speed Oil-Free Rotary Screw Air Compressors 55-75 kW
Nirvana oil-free air compressors, with a matching variable speed inverter and hybrid permanent magnet (HPM®)motor, provide unparalleled energy efficiency at all speeds along with superb reliability. They deliver ISO 8573-1:2010 Class 0 certified 100% oil-free air for the most critical applications. There are no motor bearings, pulleys, belts, couplings or motor shaft seals to wear out, leak or need replacing. Nirvana will lower your operating costs with its dynamic efficiency -- a truly transcendent technology!
Ingersoll Rand offers a wide portfolio of oil-free products that will adapt to your industry and application. From the industry that requires large volumes of flow, to the industries with a fluctuating demand that requires the use of the Nirvana oil-free VSD compressor, Ingersoll Rand will assess and propose the best oil-free solution for your needs. Ingersoll Rand will offer his expertise also for the low pressure application.
Key benefits:
- Increasing the productivity of your installation, with optimized compressed air solutions adapted and designed to match the needs of our customers;
- Peace of mind – zero risk of contamination of your final product;
- Robustness and reliability for harsh environments thanks to trusted and world class suppliers and the use of the highest quality materials.
Quality is not an option, it is essential:
- Regulatory compliance: Strict legislation exists in many countries controlling the use of compressed air in sensitive industries such as Food & Beverage or Pharmaceutical;
- Peace of mind: The use of an oil-free Class 0 certified compressor guarantees contamination-free air and ensures your total peace of mind;
- Reliability and productivity: Top quality air (oil-free Class 0 air & -40°C PDP) protects sensitive downstream equipment, for reliability, low maintenance and long life.
Reduced cost of ownership:
- Compressed air solutions using oil-free technology optimize productivity in your operation;
- Thanks to our patented rotor coating (UltraCoat®), compressor efficiency and reliability are assured throughout their working life;
- Active carbon filters are not required, eliminating the waste of energy in pressure drop;
- Maintenance
- Our equipment is designed specifically to make maintenance easy by providing clear access to consumable components.
- Reciprocating
- Rotary Screw
- Centrifugal
- Oil Free Rotary Screw
- Dryers
- Filters
- Controls
- PET Blow Molding
Nirvana Variable Speed Oil-Free Rotary Screw Air Compressors 37-45 kW
Nirvana oil-free air compressors, with a matching variable speed inverter and hybrid permanent magnet (HPM®)motor, provide unparalleled energy efficiency at all speeds along with superb reliability. They deliver ISO 8573-1:2010 Class 0 certified 100% oil-free air for the most critical applications. There are no motor bearings, pulleys, belts, couplings or motor shaft seals to wear out, leak or need replacing. Nirvana will lower your operating costs with its dynamic efficiency -- a truly transcendent technology!
FEATURES:
- 100% Oil-Free Air: Meets ISO 8573-1:2001 Class 0 specifies air quality standards for processes within the food and beverage, pharmaceutical, textile, and electronics industries
- Lower Energy Costs: Combination of variable speed operation and the Nirvana HPM® motor, along with an advanced system controller, delivers ultra-efficient peformance
- Enhanced Reliability: Stainless steel components, dual-vented seals, and precision machined-rotors with advanced UltraCoat protection ensure trouble-free operation
- Reduced Lubricant Change-Out: Industry-leading Ultra Coolant delivers up to 8,000 hours of lubricant run time, as much as 8 times the life of conventional lubricants
- High Ambient Operation: Long-life components are designed to withstand 46 ºC maximum ambient temperature
| MPDEL | CAPACITY | PRESSURE | COOLING | ||
| m3/min | ft3/min | bar(g) | psi(g) | A/C / W/C | |
| IRN55K-OF | 3.8-10.7 | 134-378 | 7 | 101 | A/C |
| 3.7-10.2 | 131-360 | 7.5 | 109 | ||
| 3.8-9.8 | 134-346 | 8 | 116 | ||
| 3.9-9.4 | 138-332 | 8.5 | 123 | ||
| 3.9-8.5 | 138-300 | 10 | 145 | ||
| 3.8-10.7 | 134-378 | 7 | 101 | W/C | |
| 3.7-10.2 | 131-360 | 7.5 | 109 | ||
| 3.8-9.8 | 134-346 | 8 | 116 | ||
| 3.9-9.4 | 138-332 | 8.5 | 123 | ||
| 3.9-8.5 | 138-300 | 10 | 145 | ||
| IRN75K-OF | 3.8-14 | 134-494 | 7 | 101 | A/C |
| 3.8-13.5 | 134-477 | 7.5 | 109 | ||
| 3.9-12.5 | 138-441 | 8 | 116 | ||
| 3.9-12.2 | 138-431 | 8.5 | 123 | ||
| 4.0-11.7 | 141-413 | 10 | 145 | ||
| 3.8-14 | 134-494 | 7 | 101 | W/C | |
| 3.8-13.5 | 134-477 | 7.5 | 109 | ||
| 3.9-12.5 | 138-441 | 8 | 116 | ||
| 3.9-12.2 | 138-431 | 8.5 | 123 | ||
| 4.0-11.7 | 141-413 | 10 | 145 | ||
| IRN90K-OF | 9.1-18.0 | 151-299 | 7 | 101 | A/C |
| 9.3-17.1 | 155-285 | 7.5 | 109 | ||
| 9.3-16.5 | 155-275 | 8 | 116 | ||
| 9.2-15.3 | 153-255 | 8.5 | 123 | ||
| 9.6-14.0 | 160-234 | 10 | 145 | ||
| 9.1-18.0 | 151-299 | 7 | 101 | W/C | |
| 9.3-17.1 | 155-285 | 7.5 | 109 | ||
| 9.3-16.5 | 155-275 | 8 | 116 | ||
| 9.2-15.3 | 153-255 | 8.5 | 123 | ||
| 9.6-14.0 | 160-234 | 10 | 145 | ||
