AC arc welding machine BX1 200C

Product Overview

Description

ac arc welding machine



FEATURES:

1. fan-cooled, Thermal protection.

2. Stepless regulation of welding current.

3. Aluminum coiled transformer, economical for amateur & family use.



ACCESSORIES:

1.1.8m welding cable with electrode holder 1 piece

2.1.2m earth cable with clamp 1 piece

3.Hand-held shield 1 piece

Model No.	MMA-2130C	MMA-2160C	MMA-2180C	MMA-2200C	MMA-2250C
	(BX1-130C)	(BX1-160C)	(BX1-180C)	(BX1-200C)	(BX1-250C)
Rated Input Voltage (V 50/60Hz)	230	230	230/400	230/400	230/400
Rated Capacity (Kw)	5	6.5	7	7.5	10
No-load Voltage (V)	48	48	48	48	48
Current Range (A)	55-130	55-160	60-180	60-200	60-250
Fuse (A)	16A	16A	20A	20A	25A
Usable Electrodes (φ mm)	2.0~3.2	2.0~4.0	2.5~4.0	2.5~4.0	2.5~5.0
Insulation Class	H	H	H	H	H
Weight (Kg)	16	18	20	21	24
Dimensions (mm)	480*275*325	480*275*325	480*275*325	480*275*325	480*275*325
