Dr.Storage T60M 1200 6 Baking 60 Dry Cabinet

Product Overview

Description

Dr.Storage T60M-1200-6 Baking 60 Dry Cabinet







Model	T60M-1200-6	T60M-600	T60M-480
Product Image
Humidity Range	60℃, <1%RH
Precision	±3.0%RH, ±1.0℃
Recovery time (Open door 30 secs)	Open door 30 seconds and close, 5 mins recovery time to <5%RH, 20 mins recovery time to <2%RH
Voltage	110V/230V
External dimensions (mm)	W1200*D770*H1805mm	W600*D770*H2005mm	W600*D810*H1580mm
Internal dimensions (mm)	W1140*D500*H1460mm	W540*D500*H1460mm	W540*D540*H1035mm
Shelf dimensions (mm)	W1080*D460*H20	W480*D460*H20mm	W480*D460*H20mm
Capacity	833L	395L	302L
No. of Shelf	5	5	3
Power consumption	Ave. 850Wh Max. 2400W	Ave. 350Wh Max. 1650W	Ave. 350Wh Max. 1650W



    T60M-1200-6 Baking 60℃ Auto Dry Cabinet is a plug and play, fully auto dry cabinet which will be stable at 60℃ and <1%RH. It is especially designed for moisture sensitive SMD packages.
