Magnesium alloy plate and sheet AZ31, AZ61,AZ91 for etching engrving, aerospace, aircraft,etc.

Product Overview

Description

Magnesium alloy plate and sheet AZ31, AZ61,AZ91 for etching engrving, aerospace, aircraft,etc.



 Magnesium alloy plate and sheet AZ31, AZ61,AZ91 for etching engrving, aerospace, aircraft,etc.

 ♦ Specifications



Magnesium alloy plate and sheet is a wrought magnesium base alloy with good room-temperature strength and ductility combined with corrosion resistance.

Thickness can be from 0.5mm to 400mm; Max. width is 1000mm; Max. length is 6000mm.



♦ Application :

Magnesium alloy plate and sheet are commonly used in etching engraving,automotive, transportation, aerospace industries,and cathodic protection, etc.



♦ Physical Properties :

Density: 1.78

Coefficient of thermal expansion: 26.8 x 10-6K-1

Specific heat: 1040 Jkg-1k-1

Thermal conductivity: 76.9Wm-1k-1

Electrical resistivity: 92nΩm

Modulus of elasticity: 45 x 109Pa

Poissons ratio: 0.35

Melting range: 566 - 632°C



♦ Chemical compositions of Magnesium plate and sheet :



AZ31B	ASTM B 107/B 107M
Elements	Al	Zn	Mn	Si	Fe	Cu	Ni	Others	Mg
Min %	2.5	0.6	0.2
Max %	3.5	1.4	1	0.1	0.005	0.05	0.005	0.3
AZ61A	ASTM B 107/B 107M
Elements	Al	Zn	Mn	Si	Fe	Cu	Ni	Others	Mg
Min %	5.8	0.45	0.15
Max %	7.2	1.5	0.5	0.1	0.005	0.05	0.005	0.3	Bal.
AZ91D	ASTM B 93B
Elements	Al	Zn	Mn	Si	Fe	Cu	Ni	Others	Mg
Min %	8.5	0.45	0.17
Max %	9.5	0.9	0.5	0.08	0.004	0.025	0.001	0.3	Bal.





 ♦ Company Simple Introduction:



We are professional manufacturer and has twenty years experience in anti corrosion industry. Our main products includes

• Magnesium casting & Extruded Anode, Magnesium Sheet and plate
• Aluminum Anode
• Zinc anode, Zinc Ribbon Anode,
• High Silicon Cast-Iron Anode
• Epoxy Coated Steel Reinforcing Bar
• Ant-corrosion Tapes

Our products are widely used to many important projects and water heater factories, Hongkong-Macau-Zhuhai bridge, Hangzhou Bay bridge, and Sinopec, Haier, AOSmith etc,.





63B Casting Magnesium Rod Anodes for water heaters, Extruded Magnesium Rod Anodes





Q.What information will be needed if I want a quotation?

A: Materials contents(Chemical Compositions) and the size of models. Special structures with drawing, Qty and delivery time.



Q. Can we visit your company/factory before place the order?

A: Welcome to visit us in China. Hopefully it will be a happy journey here.



Q: How does your factory do regarding quality control?

A: Quality is base of the company life. We working on new materials industrial for more than 20 years.



Q. What do Magnesium sacrificial anodes do?

A. Magnesium anode is used in the technical method of electrochemistry cathode protection. theory is from that connect with the protected metal body ,with the exhausting and dissolving of negative metal material or alloy ,protective curer body  will be protected from corrosion . Mg anode can produce higher quality potential power, is ideal sacrificial materials.
