2019 sweater knitting machine for home

Product Overview

Description

We have 20 years for sweater knitting machine for home

sweater knitting machine for home, 52", with comb or without comb,





sweater knitting machine for home sale parameters:



1	Guage:	5.7(Multi-gauge),5G,7G,8G,10G,12G,14G
2	Knitting width:	52”=132CM
3	Knitting speed:	max 1.2m/s (it depend the pattern and yarn quantity)
4	Knitting system:	single carriage with double system.
5	Knitting function:	transfer, tuck, pointer, intarsia, jacquard, hide, or apparent shaping and other regular or irregular patterns.
6	Racking:	controlled by servo motor racking within 2 inches and with fine adjusting function.
7	Encoder:	advanced encoder adopted.
8	Detect alarm system:	the safety alarm detect device, achieve to up-down and left-right swing function, which surmount the normal flat knitting machine with detect simply left-right swing only and great increase the detect protect function.
9	Transfer cam:	the transfer is compose designed, single or double cam system an other cam system for knitting which will achieve to high production efficiency knit.
10	Stitch density:	controlled by stepping motor with 24 sections, adjustable to different knitwear, have various of shaping and patterns. The adjustable range from 0-650.
11	Sinker system:	controlled by stepping motor, adjustable to different knitwear, have various of shaping and patterns.
12	Fabric rolling system:	controlled by stepping motor, 24 section force selection adjustable range from 0 to 100.
13	Yarn feeder:	2*8 yarn feeders on each side of 4 guide rails, shift able on any needle position ( special intarsia carriers optional if you need intarsia).
14	Protection:	The machine will auto alarm if yarn-breaking, knots, floating, yarn rewind, end of knitting, fail of racking, needle breakage and error programming occur. Also set up the safety auto-lock protect device.
15	Screen:	Adopt LCD touch screen and figure interface, input device: USB internal storage 1G, A great amount of design files can be stored at the same time and they can be fetches out for use at any time as per production requirement.
16	Monitoring menu:	Each kind of operation parament can be shown and it can be adjust at any time when the machine is running. Making conveniences for operations as much as possible.
17	Language version:	Chinese, English
18	Power;	single-phase 220V, adopt advanced CMOS technology, recovery of memory function as power shock stop (=0.6 KW/H)
19	Easy repair	The back door open by key, easy for repair.
20	Comb system	The comb moving by servo, so the force much steady.
21	Anti-interference	Use isolation transformer, prevent the power interference.
22	Measurement:	2750*8500*1800MM
23	Net weight:	1090KG
24	Goss weight:	1120KG









 We also produce the collar machine, we have sold over 600 colllar machine in the world. We sold 400 sets collar machine in Bangladesh.















We also produce

1.the hand machine

2.semi-auto machine

3.placket machine

4.re-winding machine

5.1 system, 2 system, 3 system, 4 sytem, 6 system, stoll and shima style

6.linking mahcine

7.collar machine

8.winding machine











• 1. What is your main products?
  • Our main product is computerized flat knitting machine.

• 2. What products can flat knitting machine produce?
  • Our machine can usually produce sweaters, hats, scarves, knee pads and so on.

• 3. What other product does your company offer?
  • In addition to computerized flat knitting machine, we also provide soft winding machine, linking machine, placket machine.

• 4. What is your advantages?
  • (1) We are 20 years old factory.
  • (2) We have sold over 40 coutries.

• 5. How long is the delivery time?
  • The exact delivery time depends on the quantity of the order. Usually 25~30 days after receive the deposit.

• 6. How do you provide after-sales service?
  • We have agents overseas to help after sales maintenance. And if the problem is difficult to handle, we will send the engineers to help you.
