Taidacent RF Signal Generator Simple RF Signal Source Transmitter 35MHz 4400MHz High Frequency Portable Signal Generators Module
Taidacent RF Signal Generator Simple RF Signal Source Transmitter 35MHz-4400MHz High Frequency Portable Signal Generators Module
Taidacent RF Signal Generator Simple RF Signal Source Transmitter 35MHz-4400MHz High Frequency Portable Signal Generators Module
Taidacent RF Signal Generator Simple RF Signal Source Transmitter 35MHz-4400MHz High Frequency Portable Signal Generators Module
Taidacent RF Signal Generator Simple RF Signal Source Transmitter 35MHz-4400MHz High Frequency Portable Signal Generators Module
Taidacent RF Signal Generator Simple RF Signal Source Transmitter 35MHz-4400MHz High Frequency Portable Signal Generators Module
Taidacent RF Signal Generator Simple RF Signal Source Transmitter 35MHz-4400MHz High Frequency Portable Signal Generators Module

Taidacent RF Signal Generator Simple RF Signal Source Transmitter 35MHz 4400MHz High Frequency Portable Signal Generators Module

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description



Taidacent RF Signal Generator Simple RF Signal Source Transmitter 35MHz-4400MHz High Frequency Portable Signal Generators Module


Product Description


35MHz-4400MHz RF signal generator signal source ADF4351 VFO
usb power supply, the maximum frequency is increased to 4400MHZ


Feature
- Simple RF signal source signal generator
- Core components: avr mega8 microcontroller, cost-effective single-chip, low profile version of the commonly used m16. There is a 2.56v regulated source in the peripheral ADC, which is not available in other mid-range microcontrollers.
-Adf4351: Traditional VCO + PLL + 6 series high speed bistable circuit. The output is obtained by frequency division, and the output is a square wave. The amplitude of the fundamental wave does not change much.
- This product provides a signal source for the AC channel of the device under test and analyzes the frequency-amplitude characteristics of the AC channel. Note the impedance of the measuring device.


More details
The product's operating keyboard has 15 ppt keys, 0.9.19 numeric keys, 10 "++" and "-" keys to adjust the frequency of use, and also produces emission output behavior, short press "++" or "" - "Key stepping adds 1khz or minus 1khz to the original frequency output. Pressing "++" or "-" for more than 1 second will result in continuous or continuous subtractive scan mode. 1kHz at 35kHz to 138MHz in steps; 138kHz at 138MHz. The steps are 10khz at 1550mhz and 100khz at 550mhz at 14000mhz. To end the scan, just press the "++" "-" button or the "OK" button. The OK button is the output control button. Press again to stop the transfer, launch behavior caused by "++" or "-" requires pressing "OK" twice to end the transfer, the product will show ">>" in the upper right corner. When output transmit behavior occurs, the "C" key will terminate the transmission with a frequency of zero.

Step "<>" key for continuous addition and continuous subtraction scan mode for easy adjustment, cycle to select steps "1K", "10K", "100K", "1M".

By pressing the "<>" button, the new bottom layer LCD1602 power-up defaults to "<1k>" step indication. There are four types of stepping states that can be cycled through.


Specification


item
value
Power supply voltage
DC 4.5V-5.5V
Standby current
<25mA
Emission current
<150mA
Output Impedance
50 ohms
Output frequency range
35MHz-4400MHz
Output step
1KHz-8KHz
Output power
-1dBm(W) at 150MHZ (absolute value of test power) about 1 mW


Details Images




Packing & Delivery




standard box pacakge


Company Profile




Shenzhen Taida Century Technology Co., Ltd. was born in Shenzhen in 2013. It was founded by several geeks who graduated from the top universities in China. In 2016, it moved to Guangzhou, the largest city in South China (110 km away from Shenzhen). Nowadays, Shenzhen Taida Century Technolog Co., Ltd. focuses on electronic communication product design, development, production and sales. The products are exported to the United States, Europe, Japan, Korea, Australia and Brazil, and so on.
