Multispan Tunnel Greenhouse for strawberry grape raspberry , Agricultural Green houses

Multispan Tunnel Greenhouse for strawberry grape raspberry , Agricultural Green houses

(1)We can design the greenhouse for you according to your needs

(2)Overseas engineer for guiding installation is available

(3)Hot selling multi span models: 32x16m, 32x32m, 40x16m, 40x32m, 40x40m, 40x48m, 48x48m,60x64m, 64x64m, 100x96m, 100x104m.

Standard Structure: Hot galvanized steel pipe

(1)Main pillar:100(80)x50x3mm hot galvanized steel square tubes
(2)Deputy pillar:50x50x2mm hot galvanized steel square tubes
(3)Arch pipe:32x1.5mm galvanized steel pipe
(4)Gutter:thickness is 1.5m,length is 4m
(5)Horizontal bar:32x1.5mm galvanized steel pipe
(6)Boom:32x1.5mm galvanized steel pipe
(7)Service life: 10-15years

Greenhouse Frame

(1)The frame works structure is assembled by prefabricated parts. All main parts are hot dipping galvanized after processing with zinc cover 275G/M2;
(2)Pipe Diameter:25mm,32mm ,Spacing:1.0m/1.5m/2.0 m

Covering Material

(1)80-200micron 3 layers extruding film
(2)Global light transmission : ≥ 90%
(3)Feature:Anti-fog, Anti-UV, Anti-Aging, Anti-Mildew, Anti-drip, etc.
(4) Temperature range: -40 C to +60 C. D.3 years guarantee, 5 years life

Ventilation system

(1)Roof Ventilation:Manual operation&Automatic operation

(2)Side Ventilation:Manual film roller&Automatic Roller motor

Shading System

(1)Outside Shading:55%,75%shading rate

(2)Inside Shading:55%,75%,85%,100%shading rate

Cooling System

(1)Cooling pad:

Normal height: 1.5m, 2m available for customize, thickness 100mm, (2)includes cooling pad and water supply system.
(2)Cooling fan:
1380×1380x400mm Stainless steel blade ,Fan flow:40000m3/h 380V,1100W 4sets for 1sets 36x16m greenhouse

Climate control system

(1).Create more comfortable indoor climate for your greenhouse.
(2). Accurately and automatically control growing environment.
(3). Maintain optimum conditions for your plants, flowers and vegetables with our climate control equipment.

Heating system

(1). Electric/coal/diesel oil/CNG heating fans and boiler.
(2)• Protect your plants and vegetables in cold weather.
(3)• Maximum performance for human comfort.
(4)• Raise temperature to 28℃ in winter.

Ebb&Flow(Flood) Rolling Bench

(1)Tray Materials: ABS， thickness:3.0mm, deepth:7mm.
(2)Color: Gray, UV protective abilities

Seedbed

(1)Size: L6mxW 1.5mx0.7H, silk thickness: 3mm, mesh: 3x13mm,with movable shelf.

Q1: Are you trading company or manufacturer ?

A1: We are factory.

Q2: Do you offer samples?

A2:Yes, we can send a sample to you in order to check the quality.

Q3: How to ensure the quality of the products ?

A3: Before delivery,our inspection department will examine and test the products thoroughly and carefully. Necessary test and certification can be obtained as your request.

Q4: How do I install the structure or is your company coming to install it?

A4: It is easy to install,We send install video together with greenhouse in container.Or welcome visiting our factory.We will guide you how to install it in our factory.
