1'' 2'' 4'' 6" 8" 10" 12" Large Diameter SAE 100R4 Rubber Oil Suction & Discharge Hose
Construction:
Tube: Black, smooth, nitrile rubber compound.
Application:
| Size | SAE Size | I.D. | O.D. | Max. W.P. | Proof Pressure P.P. | Min. B.P. | Min. B.R. | Weight | |||||
| mm | inch | dash | min. | max. | max. | MPa | psi | MPa | psi | MPa | psi | mm | kg/m |
| 19 | 3/4" | -12 | 18.2 | 19.8 | 34.9 | 2.1 | 305 | 4.2 | 610 | 8.4 | 1210 | 125 | 0.92 |
| 25 | 1 | -16 | 24.6 | 26.2 | 41.3 | 1.7 | 250 | 3.5 | 510 | 7 | 1015 | 150 | 1.1 |
| 31.5 | 1-1/4" | -20 | 30.6 | 33 | 50.8 | 1.4 | 200 | 2.8 | 410 | 5.6 | 810 | 200 | 1.3 |
| 38 | 1-1/2" | -24 | 36.9 | 39.3 | 57.2 | 1.05 | 150 | 2.1 | 305 | 4.2 | 610 | 255 | 1.8 |
| 51 | 2 | -32 | 49.2 | 52.4 | 69.9 | 0.7 | 100 | 1.4 | 200 | 2.8 | 410 | 300 | 2.23 |
| 63 | 2-1/2'' | -40 | 61.9 | 65.1 | 82.6 | 0.4 | 60 | 0.85 | 120 | 1.7 | 250 | 355 | 3.23 |
| 76 | 3 | -48 | 74.6 | 77.8 | 95.3 | 0.4 | 60 | 0.8 | 120 | 1.6 | 230 | 460 | 4.25 |
| 89 | 3-1/2'' | -56 | 87.3 | 90.5 | 107.9 | 0.3 | 40 | 0.6 | 90 | 1.25 | 180 | 530 | 5.05 |
| 102 | 4 | -64 | 100 | 103.2 | 120.7 | 0.25 | 40 | 0.5 | 70 | 1 | 145 | 610 | 5.6 |
Pictures Show:_________________________________________________________



1'' 2'' 4'' 6" 8" 10" 12" Large Diameter SAE 100R4 Rubber Oil Suction & Discharge Hose
1. Factory Self-introduction.
Transportide Industrial Limited is one of the largest manufacturers of hydraulic hoses, conveyor belts and related rubber products in the world. In 2010, Transportide has established two new production facilities for greater production capacity and further reduce the manufacturing cost. We will never stop our efforts to offer our customers with best products and best prices.
2. Exporting Experience of our company.
We have 27 years experience on hydraulic hose since 1989.
3. Annual Capacity.
Our annual production capacity is 6 million meters for hydraulic hoses.
4. Special Discount and Service for distributors.
Yes, Since we are focus on supply our rubber hose to Wholesalers and distributors to develop our B2B business.We will provide the most competitive price and best service to support our wholesale customers.
5. Quality Guarantee.
We have strict QC process from raw material to production,then QC before shipment.
7. Delivery Time.
For a 20feet container is about 20 days.
For a 40feet container is about 35 days.
8. Branding on the hoses.
According to customers' requestments.
