Eastern High Quality Raycus 500W Fiber Laser Source
Product Description
The third-generation medium-power single-mode continuous fiber laser developed by Raycus ranges from 50W to 1,000W, the new laser has higher electro-optical conversion efficiency (>30%), higher and more stable optical quality, stronger altitude stress-resisting capacity and it applies optimized second-generation fiber transmission system to ensure more stable and more sophisticated cutting effect in thick sheet cutting. This machine applies to many application scenarios: cutting, welding, holing, medical device processing, etc., with a narrow seam of the cut sheet and bright section. Compared with same lasers, it has obvious advantages.
High electro-optical conversion efficiency
Altitude stress-resisting capacity
Sheet cutting efficiency
Customized output fiber length
Optional QCS or QBH connector
Optional air cooling or water cooling
Maintenance-free operation
Wide modulation frequency range
Details
Model
RFL-C500
Output Power (W)
500
Center Wavelength (nm)
1080
Repetition Frequency (kHz)
50
Output Power Stability
<3%
Output Aperture Dia. (mm)
7±1
M2
<1.5
Pulse Width (ns)
<130@20KHz
Single Pulse Energy (MJ)
1@20KHz
Fiber Length (m)
2
Input Power (VDC)
24
Power Adjustable Range (% )
3
Power Consumption (W)
3000
Size (mm)
450*240*760
Cooling Way
Water cooling
Working Temperature (℃)
10-40
Packaging & Shipping
Package: packed in carton box
Shipping: by express (FedEx, DHL, TNT, UPS, etc)
About us
FAQ
1. Why choose your company?
We’re professional laser marking machines manufacturer. We’re more familiar with customer’s marking or engraving application so we’re in a position to recommend a more suitable model to customers.
2. What’s MOQ?
One piece. You can mix it with other laser machine parts freely.
