SVC 1500VA(LED) 1Phase Servo type AC Automatic Voltage stabilizer regulator AVR 220V/110VAC LED digital display

Product Overview

Description

AC Automatic Voltage Regulator Stabilizer AVR 220/110V 1Phase Single Phase Servo motor type high accuracy SVC-500VA/0.5KVA/1000VA/1KVA/1500VA/1.5KVA/2000VA/2KVA/3000VA/3KVA/5000VA/5KVA/7500VA/7.5KVA/10000VA/10KVA/15KVA/20KVA/30KVA/40KVA/50KVA/60KVA LED digital display



1. Feature:
The series product is a servo-motor type high accuracy household AC Automatic Voltage Stabilizer regulator AVR, the low power consumption, reliable work, high accuracy of stabilization, and good for use in regions where the net voltage is much fluctuating.

2. Application:
Computer, Test equipment, Lighting system, Communication system, Medical equipment, Industrial automatic equipment, Stereo sound equipment and Home or office appliance etc.

3. Specification:
Phase No.: Single phase/1 Phase
Input voltage: 160~250VAC , 150~250V, 140~250V, 100~250V, 70~250V(optional),
Output voltage: 220VAC/110VAC(0.5kVA~3kVA); 220VAC(5kVA~60kVA)
Accuracy of voltage: +/-2.5%
Frequency: 50Hz/60Hz

Display: Multi-function LED Digital display
Efficiency: >90%
Response time: <1.5s against 10% input voltage deviation
Ambient Temperature: -10C~+40C
Insulation resistance: >2MΩ
Waveform distortion: Non-additional waveform distortion
Protection function: Over voltage, over current, overloading and delay etc.

4. Remarks:
Custom-made specifications are acceptable.



5. Models:

Model	Rated Power	Package Size(Approx. )	Qty. Per Pkg
SVC-500VA	500VA, 0.5kva	42*28*36.5CM	6PCS/PKG
SVC-1000VA	1000VA, 1kva	60*30.5*23CM	4PCS/PKG
SVC-1500VA	1500VA, 1.5kva	60*30.5*23CM	4PCS/PKG
SVC-2000VA	2000VA, 2kva	54*42*31CM	2PCS/PKG
SVC-3000VA	3000VA, 3kva	54*42*31CM	2PCS/PKG
SVC-4000VA	4000VA, 4kva	54*42*31CM	2PCS/PKG
SVC-5000VA	5000VA, 5kva	54*42*31CM	2PCS/PKG
SVC-8000VA	8000VA, 8kva	64*28*31CM	1PC/PKG
SVC-10KVA	10000va, 10KVA	64*28*31CM	1PC/PKG
