High Power 10W UV led 365nm LG chip 45mil
- Category: >>>
- Supplier: Shenzhen Yingfeng Opto-Electronic Co. Ltd.Shenzhen Ltd.
Share on (60761796244):
Product Overview
Description
| Order Code | Current (mA) | VF (V) | Peak wavelength (nm) | Radiation Intensity (mW/Sr) | Radiant Power (mW) | Angle (Degree) | Half Width (nm) |
| HYF68X43B365AG-X4A | 1400 | 7.0-8.0 | 365-370 | 5436 | 4500-5500 | 60 | 9 |
| HYF68X43B380AG-X4A | 1400 | 6.0-7.5 | 380-390 | 5436 | 5500-6500 | 60 | 12 |
| HYF68X43B395AG-X4A | 1400 | 6.0-7.5 | 395-405 | 5236 | 4000-5000 | 60 | 13 |
| HYF68X43B365AG-D4B | 2800 | 3.6-4.5 | 365-370 | 4600 | 4500-5500 | 120 | 9 |
| HYF68X43B380AG-D4B | 2800 | 3.4-3.8 | 380-390 | 4600 | 5500-6500 | 120 | 12 |
| HYF68X43B400AG-D4B | 2800 | 3.4-3.6 | 395-405 | 4600 | 5500-6500 | 120 | 13 |
| HYF68X43B365AG-X4C | 700 | 13-16 | 365-370 | 5436 | 4500-5500 | 60 | 9 |
| HYF68X43B380AG-X4C | 700 | 13-16 | 380-390 | 5436 | 5500-6500 | 60 | 12 |
| HYF68X43B400AG-X4C | 700 | 13-16 | 395-405 | 5436 | 5500-6500 | 60 | 13 |
| 365+385+395+405 | 700 | 13-16 | 365-405 | 60/120 |
Warm Tip:The above parameters are for reference. Wavelength Angle, PCB can be customized according to requirements
