Poultry dehydrator cooking dryer for dead animal harmless treatment equipments

Poultry waste reception section

There is a  Material Silo For the reception and storage of poultry wast,dead animal.

There is a Pre-crushing machine in the middle in function of chopping whole animal caicasses and large pieces with aim of 50mm size piece(easily transported)

A Material Pump is at the bottom to transport the marterial to cooker.

 Cook and Dry Section

Function: Waste raw materials(feathers,animal,fur,sick livestock,animal carcasses) through the process of high temperature and pressure to achieve the effect of sterilization and break down

Features: Big capacity of each batch,the efficiency of sterilization is complete and safe.

It could be used to break,cook,sterilization and drying.

 Oil Press Section

The material from silo are sent to the heated pot by screw conveyor, and then go into the oil press,

after oil press, we get the cake with 10-12% oil and fat ,the odor from this section collected by

pipeline and is treated together.

 Cooling Section

The cake from cooker is sent to cooling system by screw conveyor(with dust collection), the tempertaure is reduced to ±5℃ room temperature.

Meal Section

Function: To reduce the size of meal.

Features: 1.Unique crushing chamber to improve the efficiency of grinding.

2.Special rotor design program,and the harmmer sieve gap,which can meet different granularity.

Packing Section

Automaticly packing the meal.

 Odor treatment section

To seperate solids and liquids entrained in the process vapoures from cooking /drying equipment,by washing of glasses collected from several process points.

 Final Products

Tallow: Moisture<1%

Meat and Bone Meal: Protein≥65%

The whole line consists of material buffer bin,conveyor,cooker dryer,grinding,packing and odor treatment system

Hebei Chengzhu Machinery Group Co., Ltd was founded in 1990, we specialized in contracting the project of poultry and livestock waste rending plant and slaughterhouse waste, after 20 years development and growth, we have become the company with technology research and development, processing design, product manufacturing, installation and training.

Our company has developed a new type of hydrolyzed feather dusting machine, which is based on the advanced technology of European and American countries, and combined with the new generation products developed by our company for many years.
