SMD 2216 5050 3528 3014 2835 5630 IP65 IP67 IP68 Waterproof Outdoor 24V Flex LED Stripe
- Category: >>>
- Supplier: Shenzhen Superlighting Electronics Co. Ltd.
Share on (60765292986):
Product Overview
Description
Product Description
SMD 2216 5050 3528 3014 2835 5630 IP65 IP67 IP68 Waterproof Outdoor 24V Flex LED Stripe
Part Number | UN-FPC-E2835NW-XXD-XXV |
Colour | 2700-6500k |
Voltage | DC 12v 24v |
LED Type | Edison SMD 3014 2835 5630 Led Chip |
Lamp Power | 5-20W/m |
Lamp Luminous Flux(lm/w) | 105lm/w |
CRI (Ra>) | 80 |
LED Light Source | Edison SMD3014 2835 5630 |
LED Qty(LEDs/m) | 60-180 |
Beam Angle(degree) | 120 |
CCT/nm | 2700-6500k |
Min. Cutting | 5cm/3LEDs |
Max. Length | 10M |
PCB Color | White |
PCB Width | 8mm |
Operating Temperature | -20-45℃ |
Storage Temperature | 0-60℃ |
Environment Humidity | 40%-70%RH |
IP Rating | IP20 IP65 IP67 |
Application | Indoor outdoor |
Certification | CE FCC ROHS |
Packaging Details | 5m/roll 10m/roll |
Warranty | 2 years |
Tips:Luminous flux plus or minus 10% is allowed in the floating
DC12V 120-degree Beam Angle 60led/m Natural White lightbar 2835 Series IP20 bare board flex LED Stripe with CE FCC ROHS
Applications Notes
◆Hotels
◆Conference/Meeting rooms
◆Commercial Purposes
◆Schools
◆Need to energy saving and auxiliary lighting, decorative lighting
DC12V 120-degree Beam Angle 60led/m Natural White lightbar 2835 Series IP20 bare board flex LED Stripe with CE FCC ROHS
Product packaging
Model | Part Number | Rolls/Box | Net Weight/box | Carton Size(mm) |
DC12V 1M 60LED 2835 | UN-FPC-E2835NW-60D-12V | 100 | 9KG | 500X300X200 |
