  • 2 feet Graph plotter with U disk driver and step motor
2 feet Graph plotter with U disk driver and step motor
2 feet Graph plotter with U disk driver and step motor
2 feet Graph plotter with U disk driver and step motor
2 feet Graph plotter with U disk driver and step motor
2 feet Graph plotter with U disk driver and step motor
2 feet Graph plotter with U disk driver and step motor
2 feet Graph plotter with U disk driver and step motor

2 feet Graph plotter with U disk driver and step motor

Share on (60765341194):


Price:$310.00 - $420.00

Quantity:


Product Overview

Description


Product Description

Features

1.AAS Automatic registration

2.Work offline with u disk

3.Automatic contour cutting

4.support all windows and mac system

5.1000g cutting force


\t
Model
\t
C-24AX
\t
Media way
\t
optional
\t
Main board
\t
32-bit ARM7 CPU 168 MHZ,128MB, High-speed CACHE memory
\t
Control panel
\t
9 industrial silicone buttons and 128*64 industrial screen
\t
Driver
\t
High speed, big power step motor, micro-step motor
\t
Maximum paper feed width
\t
790mm
\t
Maximum cutting width
\t
680mm
\t
Maximum cutting speed
\t
600mm/s
\t
Cutting force
\t
10-1000g(digital adjustment)
\t
Mechanical precision
\t
0.025mm
\t
Repeatable precision
\t
<0.025mm
\t
Type of plotter pen
\t
all types diameter 11.4mm plotter pen
\t
Plotter instruction
\t
compatible DM/PL,HP/GL
\t
Interface
\t
USB/U disk/serial port, Ethernet port /wifi(optional)
\t
Power supply
\t
AC220V/110V,50HZ
\t
Power consumption
\t
<80w
\t
Knife/blade
\t
imported hardness alloy steel blade
\t
Operating environment
\t
temperature: 5-35 degree, relative humidity: 30%-70%
\t
Package size
\t
1075*324*380
\t
Gross weight
\t
25kg
Detailed Images
Factory profile
Certifications
FAQ

1. what you can do by using our cutting plotter?

  Cutting vinyl patterns and letters in T shirt, cutting wall/car sticker, cutting window film, cutting DIY     leather, cutting road sign, cutting special-shaped label, cutting sandblasting glass..........

2. What is the maximum cutting thickness?

     1mm


3. what system our machine can compatible?
      All windows and Mac systems


4. what software machine can support?
      All professional drawing software, just like Coreldraw, AI, Signmaster, Flexi, Artcut and so on

5. what the machine will come with?


6. How about the after sale service?

We have a technical department which consist of several technical man, they are specialize in supply customer technical service

We will supply teamviewer software , the technical man can telecontrol to fix question.

Provide the detailed operation manual and operation video.
