5KW open type good quality portable diesel generator with CE 5GF

Product Overview

Description

PRODUCT DESCRIPTION

DIESEL GENERATOR SET

Model:5GF

Type:Revolving field type 2 pole generator

Rated Power Output:4200W

Max Power Output:5000W

Rated Voltage:220/380V

Rated Current:18.3A/20.8A

Frequency:50/60Hz

Engine Speed:3000RPM

Phase:Single/Three

Power Factor:1

Excitation system:Controlled Constant Self-excitation

DC output V/A:12V/8.3A

Operation Capacity:12 hour Constant Operation

Coupling Pattern:Straight shaft coupling

Engine Model:186FG

Engine Type:Direct injection Vertical,4-cycle,air-cooled diesel engine

Displacement:406cc

Max.Output:6.6/7.35 KW/rpm

Cont.Output:5.9/6.6 KW/rpm

Starting system:Recoil/Electric

Governor system:Centrifugal weight system

Fuel:Diesel light fuel(BS-AL or equivalent)

Fuel Tank Capacity:15L

Lube Oil Capacity:1.65L

Bore×Stroke:86×70mm

Protection System:Low oil,Warning system/Stop Device(not for L-series)

Niose level at 7m:85dB

G.W./N.W.:95KGS

Dimension:720×480×580MM

ADVANTAGES

1. Easier to start,100%Copper Motor.

2.Overload protection for safe running.

3.Solid Muffler to reduce the noise.

4.Waterproof Protection for the OFF/ON switch.

5.Full frame protection for easy transportation and carry.

6.Compact, light and portable power source for entertainment, emergency and home use.

7.Economical, low fuel consumption for continuous stable running .

8.Easy maintenance with brush-less alternator and electronic ignition.

9.Standard configuration of voltmeter enables convenient use.

10.AC/DC circuit breaker ensure safety for its overload and shock circuit protection.

11.100% testing with loaded before packing.

12.With CE,GS,ROHS,ISO9001,TUV,SONCAP certification.

13.12 months warranty for long sevices life.

14.Reasonable price with higher quality.

COMPANY PROFILE

HUAHE HEAVY INDUSTRIES CO.,LTD. Is located in the land scope shore of east china sea.jinqing town,luqiao district,taizhou city,zhejiang province.which is a

key base in producing generator forklift in China presently.The company was founded in 1990,managerial philosophy of company is that”hold together and innovation,keep on aggressiveness ,pursue superiority”.It will make the company to explode constantly and it has passed GS.TUV.ROHS.EPA.ISO9001:2000 quality system certification CE.

We develop a new field,ZHEJIANG HUAHE FORKLIFT CO.,LTD.which located at Binhai industrical zone of Sanmen county,mainly focusing on forklifts.

Our company has 600 employees,over 200 manager ad technicians,90% of which graduated from college.The area of factory building 60000 square meter,annual output value more than USD 50,000,000 and our factory has more than ten modern production lines and advanced equipment and perfect monitor and measuring device such as puncher,driller,lathe,measuring truck,cutter,shielded welder and pipe bending machine.

Main products of company are forklift,all kinds of generators including gasoline

and diesel series,water pumps,tiller,high pressure washer,grass cutter,welding machine,Twith full range of specification,and stable quality and advanced technology,which have been selling very well in middle east,America,Europe,

Southeast Asia,Africa,and other countries etc.

President Mr HEPING SHI leads all staffs of company to welcome you visit and contact us at any time,Let us join hands to initiate bright future together.

PRODUCTION DEPARTMENT

PACKING AND LOADING

CERTIFICATION

OUR TEAM
