AAR standard Wheelset for Railway Vehicles

Name: AAR standard Wheelset for Railway Vehicles
SKU: 60766238268
Availability: InStock

Price:

Quantity:

760mm wheelset

1. Drawing

760mm wheel +2160mm axle

760mm wheelset (2).jpg

760mm wheelset.jpg

2.Main dimension:

Product NO.	MTJ760WHEELSET
Wheel outer diameter	760 mm
Wheel material	CL60
Axle length	2160 mm
Axle material	LZ50
Distance between the internal wheel faces	1353 mm

3.We can offer:

Railway axle
Length, L/mm	Distance between two journal centers,L1/mm	Axle journal diameter,D1/mm	wheel seat diameter,D2/mm	axle body diameter,D3/mm	alxe load/t
2062-2356	1905-2007	100-180	155-241	138-215	12-35

Forging Part	Forged steel rail wheel and wheelset
Material	ER6,ER7,ER8,ER9,R7T,R8T,R9T,CL60
Dimension	According to your drawings
Application	Heavy industrial equipment
Inspection	Chemical composition; UT,MT; mechanical property; dimension check
Standard	IRS,BS,UIC,AAR,BN,GB,TB/T,EN
QC Doc	Chemical composition report mechanical properties report; UT test report; heat treatment report; dimensions check report.
Forging Processing	Ingot---forging---heat-treatment---rough machining---UT.MT---Q+T---inspection---finishing machining---UT.MT---packing
Heat Treatment	Normalized / Annealed / Quenched / tempered


Maanshan forging steel wheel axles

Packaging & Shipping

Maanshan forging stainless steel wheel axles
