1. Module uses USB and serial communication with the outside world to facilitate the module and the PC , microcontroller connection.

2. The module's normal operating voltage is 5V , and the ICSE014A (8- way relay ) module is configured with a 5V power connector .Specific parameters in the table below:


interface

Three modules are equipped with MICRO USB and TTL level serial interface. Specific configuration is as follows:

1. MICRO USB: Standard mini USB port, through the USB extension cable to communicate directly with other devices such as PC .

2. TX: serial interface sender.

3. RX: serial interface receiver.

4. 5V: Positive power supply.

5. GND: power ground.

6. 5V power outlet : ICSE014A only , MICRO USB power shortage used.Our Services
