Food/pharma grade Stainless Steel Braid Cover Smooth PTFE Tube For transporting corrosive chemicals, hot air, hot oil, steam
- Category: Plastic Tubes >>>
- Supplier: Cjan Fluid Technology Co. Ltd.
Share on (60767517509):
Product Overview
Description
Product Description
Stainless Steel Braid Cover Smooth PTFE Tube
Construction:
Type TSS is manufactured from smooth PTFE tube with stainless steel over braid.
Temp. Range: -70℃~260℃.
Applications:
For transporting corrosive chemicals, hot air, hot oil, steam and so on where a closed Bending radius is not required. Not recommended for steam-cold water cycling.
Virgin and anti-static liners are available.
Certification: F.D.A.
We also can provide Type PSS (PFA tube).
Part no. | ID | OD | Tube Wall thickness | Bending | Work pressure | Bursting pressure | |
in. | mm | mm | mm | mm | bar | bar | |
TSS003 | 1/8" | 3.2 | 6.2 | 1.00 | 60 | 250 | 750 |
TSS005 | 3/16" | 4.8 | 7.7 | 0.75 | 60 | 200 | 600 |
TSS006 | 1/4" | 6.4 | 9.2 | 0.65 | 75 | 185 | 555 |
TSS008 | 5/16" | 7.9 | 11.2 | 0.75 | 100 | 180 | 540 |
TSS010 | 3/8" | 9.5 | 12.4 | 0.75 | 125 | 170 | 510 |
TSS013 | 1/2" | 12.7 | 15.9 | 0.75 | 140 | 130 | 390 |
TSS016 | 5/8" | 15.9 | 19.3 | 0.90 | 160 | 100 | 300 |
TSS019 | 3/4" | 19 | 22.8 | 0.90 | 200 | 75 | 225 |
TSS022 | 7/8" | 22 | 26.0 | 1.00 | 300 | 65 | 195 |
TSS025 | 1" | 25.4 | 29.5 | 1.05 | 400 | 65 | 195 |
Company Information
CJan is a dynamic and versatile hose and fittings manufacturing company. We export our products to our customers all over the world and are recognised for our food-safe rubber hoses, silicone hoses, Teflon hoses, FEP/PFA lined fittings as well as sanitary stainless fittings.
First in China
1. FOOD RUBBER HOSES are first approved by SGS and pass F.D.A 21 CFR 177-2600 test in China.
2. FEP or PFA LINED FITTINGS are first liquefy-sintering fittings in China.
3. SILICONE HOSES are first approved by SGS and pass F.D.A /USP test in China.
- Certificate of Patent - F.D.A Test Reports
Packaging & Shipping
Our Equipment
Exhibition
FAQ
1. Are you manufacture?
We started business from trading, but now we have invested and holded several factory in china.
2. Can you ship to my country?
We can ship to all the countries around the world by air or sea.
3. How much is the shipping charge to my country?
It depends on your country located and the weight of goods.
4. What's the price term?
EXW, FOB, CIF, CFR
5. What's your payment?
T/T, L/C, Western Union
