Shopping Center Good Price Escalator Automatic Start Stop Indoor Escalator
- Category: >>>
- Supplier: Volkslift-Schindler Elevator Co. Ltd.
Share on (60768859614):
Product Overview
Description
The perfect experience is what VOLKLIFT devoted to you with all our heart
| Step width(A) | Lift height(H) | Motor Power(KW) |
| 800 | 2500-3670 | 5.5 |
| 3671-4800 | 7.5 | |
| 4801-5100 | 8 | |
| 5101-6600 | 11 | |
| 6601-7500 | 13 | |
| 1000 | 2500-2950 | 5.5 |
| 2951-3900 | 7.5 | |
| 3901-4100 | 8 | |
| 4101-5490 | 11 | |
| 5491-6150 | 13 | |
| 6151-7000 | 15 | |
| 7001-7500 | 16 |
| Step width(A) | A | B | C | D | E | F |
| 800 | 800 | 1038 | 1400 | 2900 | 3550 | 1400 |
| 1000 | 1000 | 1238 | 1600 | 3300 | 3950 | 1600 |
| Step width(A) | Intermediate support | Supporting force R1 | Supporting force R2 | Supporting force R3 | Supporting force R4 |
| 800 | 0 | R1=(0.0039L+9.5)*2 | R2=(0.0039L+4.5)*2 | ||
| 1 | R1=(0.0039L+9.5)*2 | R2=(0.0039L+4.5)*2 | R3=0.00507*L*2 | ||
| 2 | R1=(0.0039L+9.5)*2 | R2=(0.0039L+4.5)*2 | R3=0.00507*(L+L)*2 | R4=0.00507*(L+L)*2 | |
| 1000 | 0 | R1=(0.0045L+11)*2 | R2=(0.0045L+5)*2 | ||
| 1 | R1=(0.0045L+11)*2 | R2=(0.0045L+5)*2 | R3=0.00585*L*2 | ||
| 2 | R1=(0.0045L+11)*2 | R2=(0.0045L+5)*2 | R3=0.00585*(L+L)*2 | R4=0.00585*(L+L)*2 |
