Diesel dd series hydraulic guide rod diesel driver pile hammer

Technical parameters for hydraulic hammer frame

KLB WALKING TYPE

TB80

Movement type

footstep walking-type

Leader heigh t(m)

24

Distance between guide rail(mm)

600

Max stroke of inclined-support cylinder(mm)

1500

Max ground gradient (°)

5

main winch

single pulling force(KN)

50

Speed(m/min)

32

Wire diameter(mm)

19

vice winch

single pulling force(KN)

40/40

Speed(m/min)

24

Wire diameter(mm)

15

Walking device

Londitudinal stroke (mm)

1800

Horizontal stroke (mm)

800

Walking speed (m/min)

5

Stroke for supporting leg cylinder (mm)

1100

Revovling mechanism (°)

360

Standing way

push forward

Hydraulic system

Pressure (Mpa)

20

Power (KW)

2*18.5

overall dimension(L*W)

13m*7.5m

total weight(T)

60
