Atlas Copco Drill rigs and rock drills (AC Drill rigs and rock drills ) Simba E7 C ITH: Long hole drilling rig

Atlas Copco Drill rigs and rock drills (AC Drill rigs and rock drills ) Simba E7 C ITH: Long hole drilling rig

Category: >>>
Supplier: Shanghai Compressor Service Co. Ltd.

Price:

Quantity:

Product Overview

Description

Atlas Copco Drill rigs and rock drills (AC Drill rigs and rock drills ) Simba E7 C-ITH: Long-hole drilling rig

Simba E7 C-ITH is a long-hole drilling rig for medium- to large-sized drifts in the 95 to 178 mm hole range. The rig is capable of ring drilling parallel holes upward and downward with up to 5.9 m spacing. Equipped with a high-performance pneumatic in the hole hammer, the Simba E7 C-ITH offers a sustainable high-precision solution for long-hole drilling.

Features & benefits

Rod carousel for 27+1 rods for mechanized drilling up to 51 m.
The Simba E7 C-ITH is controlled by the reliable, computerized <a href="//atlascopco.com/rcs/">RigControl System (RCS)</a>, which ensures precision, productivity and also ergonomic relief for the operator.

Simba 1254

A hydraulic production drill rig made for limited tunnel sizes.

Robust production drill

Maneuverable rig

Efficient drilling

Ergonomic controls and accessible service points make it easier for operators to reach higher levels of production.

Precise drill rig

The Simba 1254 is a hydraulic production drill rig made for limited tunnel sizes. The high penetration rock drills give you the power to increase your production, no matter the rock conditions. Dual stingers with an angle reading system make setup quick and easy, while increasing drilling stability and accuracy. Ergonomic control and accessible service points make it easier for operators to reach higher levels of production. When you need a high-precision, hard-working rig for long-hole drilling, you can rely on the Simba 1254.

TECHNICAL DATA

Coverage, max. width	0 mm
Coverage, max. height	0 mm
Hole diameter	64 mm - 89 mm
Rod handling system (RHS)	0
Hole length	0 m
Rock drill	COP 1838+
Diesel engine	912 kW

DIMENSIONS

Length, tramming	0 mm
Width, tramming	0 mm
Height, min. protective roof	0 mm
Height, min. cabin	0 mm
Height, tramming	0 mm
Turning radius, inside	0 mm
Turning radius, outside	0 mm
Operating weight	12 500 kg

Download

Simba 1254 technical specification

Simba E7

Hydraulic long hole production drill rig for medium to large size drifts.

Versatile drilling rig

Easy to customize

Operator assistance

This reliable rig is equipped with a boom-mounted drilling unit for improved versatility, adaptable to any challenge.

Flexible and reliable rig

The Simba E7 is a hydraulic long hole production drill rig for medium to large size drifts, with hole range from 51 up to 127 mm. It accommodates a range of drill bits, rock drills and in-the-hole hammers to adapt to your specific needs. This reliable rig is equipped with a boom-mounted drilling unit for improved versatility, adaptable to any challenge. With the The Simba E7, you can drill parallel holes upward and downward with up to 6.9 m spacing. The rig can be operated by remote control to enhance production and operator safety and comfort. When you need a hard-working, high-precision rig for long-hole drilling, rely on the Simba E7.

Downloads

Simba E7 technical specification

Quick facts

Metric
US/Imperial

TECHNICAL DATA

Coverage, max. width	8 000 mm
Coverage, max. height	8 700 mm
Hole diameter	89 mm - 127 mm
Rod handling system (RHS)	27
Hole length	51 m
Control system	RCS
Rock drill	COP 3060MUX
Diesel engine	120 kW

DIMENSIONS

Length, tramming	12 748 mm
Width, tramming	2 550 mm
Height, min. protective roof	2 450 mm
Height, min. cabin	3 150 mm
Height, tramming	3 150 mm
Turning radius, inside	4 400 mm
Turning radius, outside	7 300 mm
Gradeability, max.	1:4
Operating weight	27 500 kg

Simba M6

Long-hole production drill rig for medium to large-drift mining

Long-hole drilling

Flexibility and precision

Remote operation

The rig operator enjoys excellent visibility and enhanced safety in the comfortable cabin.

Fast, precise rock drilling

The sturdy Simba M6 is a long-hole production drill rig for medium to large-drift mining with holes ranging from 51 to 178 mm in diameter. It accommodates a range of drill bits, rock drills and in-the-hole hammers to adapt to your specific needs. The rig operator enjoys excellent visibility and enhanced safety in the comfortable cabin. Tele-remote control capability allows for control of one or more machines from a safe and comfortable location. Your Simba M6 can then continue to drill through personnel breaks and shift changes. When you need a hard-working, high-precision solution for long-hole drilling, rely on the powerful Simba M6.

Downloads

Simba M6 technical specification

Replacement parts & kits

Financial solutions

Simba M4

Hydraulic production drill rig for medium-to-large holes

Powerful production drill

Sturdy rock drilling

Easy automated drilling

Simba M4 can be operated by remote control to increase production and operator safety and comfort.

Fast and accurate drill

Simba M4 is a hydraulic production drill rig for medium-to-large holes ranging from 51 to 178 mm in diameter. It accommodates a range of drill bits, rock drills and in-the-hole hammers to adapt to your specific needs. Simba M4 becomes even more efficient when equipped with automated single-hole or multi-hole drilling functions. The rig can be operated by remote control to increase production and operator safety and comfort. When you need a hard-working, high-precision rig for long-hole drilling, rely on Simba M4.

Downloads

Simba M4 technical specification

Drill rigs

Production drill rigs

Simba S7

Game changing precision

Superior long-hole drilling

Smarter underground drilling

Flexible and reliable rig

Trick shot - Game changing precision

Simba S7 offers a sustainable high-precision solution for long-hole drilling.

Increased drill performance

Simba S7 is built on a modern design sharing many components in common with the successful Boomer S1 face drilling rig. Simba S7 is a long-hole drilling rig for small to medium sized drifts in the 51 to 89 mm hole range. The rig is capable of ring drilling with parallel holes upward and downward with up to 5,9 m spacing. Equipped with a high-performance tophammer rock drill and boom-mounted drilling unit Simba S7 offers a sustainable high-precision solution for long-hole drilling. Increased automation lets you add the functionality you need to this versatile rig.

Downloads

Simba S7 technical specification

Drill rigs
Production drill rigs

Production drill rigs

Long-hole drilling rigs

Epiroc’s long-hole drilling rigs are used for production drilling in underground mining applications. With a variety of feed lengths, positioning configurations, rock drills, and an extensive options program; we offer the optimum long-hole drilling rig for every application. The computerized Rig Control System, RCS, offers different levels of automation. You can add options like a bit changer, a collar pipe installer, or even multi-hole automatic drilling. The latest released option is the tele-remote function, providing an edge in safety when drilling and utilizing the machine.
