Релейный выходной модуль Advantech ADAM 4060 DE 4 ch

Product Overview

Description

Main Features:

• 4-channels relay, two Form A and two Form C
• Breakdown voltage: 500 VAC (50/60 Hz)
• Insulation resistance: 1000 M ohms minimum at 500 V DC

 The ADAM Relay Output Module is a low-cost alternative to SSR modules. The ADAM Relay Output Module provides four relay channels, two of Form A and two of Form C. This module is excellent for ON/OFF control or low-power switching applications





ADAM-4060-DE
		Quote
Display	LED Indicators	Power
Power Supply	Power Requirement	10~30 VDC
General	Watchdog Timer	System (1.6 second)
	Connector	2 x plug-in terminal block (#14~22 AWG)
	Temperature (Operating)	-10~70 °C (14~158 °F)
	Humidity	5~95 %RH
	Temperature (Storage)	-25~85 °C (-13~185 °F)
	Interface	RS-485
	Isolation Protection	Breakdown voltage: 500 VAC (50/60 Hz)
	Communication Protocol	ASCII command
	Communication Speed	Serial: From 1,200 to 115.2 k
	Comm. Distance	Serial: 1.2 km
	Data Flow Control	Yes
Digital Output	Channels	4-ch relay







• LED status indicators
