Small cnc water jet cutting machine price

Share on (60769479619):


Price:$36,000.00 - $38,000.00

Quantity:


Product Overview

Description



Product Description






Features:

•\t50 HP High  420 MPa pressure for smooth finish cutting at high speed.
•\tMain heart of Supercharger, "Intensifier" is "Made in USA".
•\tUser friendly & minimum maintenance cutting head design with USA make "Water Switch Seal Kit" & other parts.
•\tAll parts of machine are processed on Highly accurate YASKAWA servo motor (made in Japan). Which gives you trouble free operation & long life of parts.

• Ability to cut the most intricate stone, tile and marble designs. Ideal for cutting up to 12"(30 cm) of materials depending on density of product. Eliminates the risk of discoloring or deformation







SPECIFICATIONS FOR WATER JET CUTTING MACHINE
Max. pressure
380-420MPA
Max. flow rate
3.7L / min
Electrical source voltage
3 phases 220/380 Voltage, 50/60Hz, 37KW, 50HP
Max. diameter of nozzle / orifice
1.02mm / 0.33mm
Max. delivery capacity of oil pump
106L / min
Max cutting heads
1-10 cutting heads (1 for standard machine)





The laser sensor system is widely used in metal and stone industry. The device can detect the flatness of the cutting materials in advance so that automatically adjusts the distance between the cutting head and the material surface. Not only does it ensure high-quality cutting but also avoids the collision between the cutting head and the material. If you are using water jet cutter for cutting metal board or stone board, it is recommended to adapt this device.




\t\t\t\t\t\t\t\t\tMachine parts show \t\t\t\t\t\t\t


water jet software

* To control all the cutting process
* Shanghai "WEIHONG"brand
* Easy to operate in just 8 hours to learn








\t\t\t\t\t\t\t\t\tDetailed Images \t\t\t\t\t\t\t






Cutting Samples


Designed & manufactured to perfection, we are one of the well known and leading manufacturers and exporters of Water Jet Cutting Machinery. At our premises, we are manufacturing the cutting machinery utilizing premium quality of raw materials and components. In addition to this, the cutting machinery is best known in the market due to its remarkable features such as high performance, easy operation and durability. This Machinery finds usage in many application such as automotive, aerospace and electronics for cutting metals and non metals.





Service & FAQ


>>>Try to Read This -------Our Service

1. Maintenance free of charge for 12 months .
2. We will provide the consumable parts at an agency price.
3. 24 hours online service, free technical support.
4. Machine has been adjusted before delivery, operation disk is included in the delivery. If there is any other questions, pls kindly tell me.
5. We have manual instruction and Videos for software Installation, operation and machine's using and maintenance; We will send professional technician to customers' factory, provide them two-weeks training, including working principle of machine, Auto CAD drawing, common problems and solution, etc.





>>>Try to Read This -------FAQ
Q1: Does This Machine Pass CE Certificate?
A2: Yes, this machine passed European CE certificate and meet Safety Standard.
Q2: How much of cutting thickness?
A2: Marble is 0-120mm; granite is 0-110mm; tiles are 0-40mm; glass and mosaic is 0-80mm; steel, stainless steel, copper is 0-60mm; aluminum is 0-80mm; plastic, acrylic, foam is 0-200mm. With our double-pressures system, it can cut 0-160mm steel sheet, 0-200mm stones. It is good for customers cut thicker materials.
Q3: How fast of speed?
A3: Speed depends on cutomers' materials and cutting requirement, and customers can adjust speed parameters.







\t\t\t\t\t\t\t\t\tAbout our company \t\t\t\t\t\t\t












Packing & Delivery






Our Package Advantage:
1. Our Wooden Case is after fumigation treatment. Needn't timber inspection,saving shipping time.
2. All the spare parts of the machine were bovered by some soft materials,mainly using Pearl Wool.
Avoiding all damages that could happen in the delivery process.Then we'll covered plastic wrap out it tightly, make sure intact of the covered soft materials,also avoiding Waterproof and rust proof.
3. The outmost is Wooden Case With Fixed Formwork.
4. The bottom of the wooden case has firm iron jack,convenient to Handling and transport.


Before delivery, we would do the test about 20-30 working hours for machine, and use standard packing to each configuration. We choose famous export company and transport company, making shipment more convenient and safer.



HEAD WATER JET MAKES CUTTING IS NO LONGER PROBLEM !
