10KN Worm Screw Jack and Worm gear worm elevator lead screw jack hand screw reducer for table lift system

Share on:

Price:$95.00 - $155.00
Price in USD:Details


Product Overview


10KN Worm Screw Jack and Worm gear worm elevator lead screw jack hand screw reducer for table lift system.


1. Maximum lifting capacities 10KN
2. Lifting screw sizes Tr 20x4
3. Worm gear ratios 1:5, 1:20
4. Custom made lifts height 10-1500mm
5. End fittings: top plate, clevis end, threaded end, plain end, forked head and rod end
6. Screw designs: translating, keyed, rotation screw design
7. Power source: manually operation (hand wheel) or electrically operated (electric motor)
8. Single unit or multiple units 10KN Worm Screw Jack lifting system arrangements

10KN Worm Screw Jack main components with international standard materials: The main components are trapezoidal lifting screw (worm screw) with No.45 steel material, worm gear or travelling nut with bronze material, worm shaft with heat treatment No.45 steel material, thrust bearings, grease seals and gear housing with ductile iron.

1521 (1).jpg1521 (2).jpg1521 (3).jpg1521 (4).jpg1521 (5).jpg1521 (6).jpg

SCREW JACK APPLICATIONS: Blast door locks, Headbox unit for paper machine, Tooling machine bed adjustment, Textile, steel, rubber, plastics skewing roll adjustments, Pinch value control actuation, gate and ball valve, Tension testing machines, Packaging machinery, Diagnostic scanners, Work platforms, Injection molding machines-head adjustment, Mechanical brake linkage adjustment, Curing processes-constant speed, Feed rate movement, Air dampers, Sheet slitter, Angle tilt adjustments with double clevis models, Remote contamination lifts, Precision closures, Solar panel actuation, Tension adjustment of cables, Welding positioners, Centerless grinder positioner, Locking indexing pins, Batch control, Palletizer indexing, Oven lifters, and Door openers.



worm screw jack (1).jpgworm screw jack (2).jpg

Drawing Dimensions

About 2D Autocad dwg, dxf assembly drawings, and 3D stp, step, model, igs, prt or catpart assembly drawings, please contact Jacton Industry directly.


Packaging & Shipping

1. Ocean freight: seaport to seaport, price terms CIF, FOB, EXW, CFR etc.
2. Air freight: airport to airport, price terms EXW, CRF etc.
3. Air courier: DHL, FEDEX, UPS, TNT door to door shipment, price terms DDU, CPT etc.
100% standard exporting plywood cases.

Note: International Exporting Standard Wooden Material with Free Fumigation.

5 - .jpg

Our Advantages

* One of the biggest orders with 1750 units screw jacks.
* Standard products with 2D Drawings(DXF, DWG, PDF) and 3D CAD Model(STEP).
* 100% quality assured with double quality inspections. Original Inspection Reports, Operation Manual, and Book Catalogue are put into the packages.
* 100% safety transportation with strong standard export plywood cases materials (free fumigation).
* International standard materials for all standard products.
* Custom design available, OEM service available, Free engineering advice and Customer label available.
