Product Overview
Description
Atlas Copco Drill rigs and rock drills (AC Drill rigs and rock drills ) Scaletec LC: Scaling rig
Scaletec LC is a fully mechanized scaling rig for tunnelling and mining applications. The Rig Control System (RCS) gives you full control of positioning and percussion. The BUT SC boom with its patented design gives maximum reach from a single setup. The rig is equipped with either a four-cylinder (standard) or 6-cylinder (optional) low-emission diesel engine for hi-speed tramming between sites. Scaletec LC uses the L-size carrier.
Features & benefits
- Rig Control System (RCS) controls positioning and percussion for high precision and productivity.
- Atlas Copco SB 302 Scaler hammer optimized for scaling ensures high productivity.
- FOPS-approved cabin, with its single seat concept, 375 mm vertical cabin lift, and 15-degree cabin tilt provides safety with optimized visibility and ergonomics.
- BUT SC boom’s unique, patented boom design and mechanical parallel holding system maximizes coverage area.
Technical data
| Air system | |
|---|---|
| Capacity, max | 10 l/s at 7 bar |
| Air pressure gauge | Yes |
| Hydraulic driven axial piston motor | 10 cc |
| Air receiver | 80 l |
| Boom | |
| Boom | BUT SC |
| Parallel holding | mechanical (3) |
| Weight, boom only | 2700 kg |
| Carrier | |
| Engine | Deutz TCD 2013L06 2V |
| Articulated steering | ±40 steering angle |
| All-wheel drive | Yes |
| Hydrostatic power steering system | Yes |
| Transmission | |
| Axle, front | Dana 114 |
| Axle, rear | Dana 114, ± 8 oscillation |
| Differential lock on front axle | Automatic |
| Clearance outside axles | 15 |
| Tires | 12.00xR24 XZM |
| Service brakes | 2 separate circuits |
| Hydraulic jacks, rear | 2 |
| Emergency and parking brakes | SAHR |
| Fuel tank, volume | 100 l |
| Exhaust catalyser | Yes |
| Electrical system | 24 Volt |
| Silencer | Yes |
| Batteries | 2x125 Ah |
| Tramming lights | 8x40 W LED |
| Tramming speed on flat ground | >15 km/h |
| Tramming speed on incline 1:8 | >5 km/h |
| Brake lights | Yes |
| Illuminated stairs for platform | Yes |
| Fire extinguisher | Yes |
| Central lubrication system | Yes |
| Spirit level | One for longitudinal and one for sideways |
| Horn | Yes |
| Beacon warning lamp | Yes |
| Reverse alarm | Yes |
| Shelf for hammer chisels and tools | Yes |
| Manual rig washing kit | Yes |
| Manual lubrication kit | Yes |
| Adjustable shovel blade in the front end with hydraulic jacks | Yes |
| Power rating | 173 kW at 2300 rpm |
| Torque | 572 Nm at 1400 rpm |
| Control system | |
| Control system | Rig Control System, RCS |
| Electronic control panel | Yes |
| Transfer of data and back-up settings | USB |
| Integrated diagnostic system | Yes |
| Adjustable operating parameters | Yes |
| Cabin | |
| Cabin, FOPS-approved, noise level <80 dB(A) | Yes |
| Swingable seat for operating and tramming | Yes |
| Rubber-damped for comfort during tramming and scaling | Yes |
| Safety glass in front window, 24 mm | Yes |
| FOPS-approved protection bar in front of cabin | Yes |
| Socket for communication radio | 12 Volt |
| Electrical socket for accessories | 230 V (10 A) |
| CD-changer | Yes |
| Lift and tilt system | Yes 6 |
| Air conditioning unit, with heating function | Yes |
| Fire extinguisher | 6 kg |
| Dimensions and weight | |
| Width, shovel blade | 2574 mm |
| Height, fixed cabin | 3107 mm |
| Height, lifted and tilted cabin | 3732 mm |
| Turning radius, inner | 4250 mm |
| Turning radius, outer | 7250 mm |
| Ground clearance | 337 mm |
| Length | 13310 mm |
| Electrical system | |
| Total installed power | 63 kW |
| Main motors | 1x55 kW |
| Starting method | Star/delta |
| Overload protection for electric motors | Electronic |
| Digital volt/amperage meter in electrical cabinet | Yes |
| Phase sequence indicator | Yes |
| Earth fault indicator | Yes |
| Battery charger | Yes |
| Transformer | 8 kVA |
| Frequency | 50-60 Hz |
| Voltage | 400-1000 V |
| Dual controls for cable reel | Yes |
| Limit switch for cable reel | Yes |
| Cable reel | Yes |
| Hydraulic system | |
| Hydraulic pumps | 2 variable pumps and 1 gear pump |
| Pumps unloaded at start | Yes |
| System pressure, max | 250 bar |
| Hydraulic oil tank volume | 200 - 250 l |
| Low oil level indicator | Yes |
| Oil temperature gauge on oil tank | Yes |
| Electrical oil filling pump | Yes |
| Water cooled oil | Yes |
| Filtration | 16 µm |
| Hydraulic oil | Mineral |
| Water system | |
| Water booster pump | Hydraulic, Flygt |
| Water inlet pressure, min | 2 bar |
| Water pressure gauge | Yes |
| Water flow guard | Yes |
| Hydraulic drive, axial piston motor | 5 cc 3 |
| Capacity, max | 125 l/m at 9 bar |
Atlas Copco Drill rigs and rock drills (AC Drill rigs and rock drills ) Boltec LC-DH: Rock bolting rig
Boltec LC-DH is a diesel hydraulic, fully mechanized rock bolting rig for bolt lengths from 1.5 to 6 meters. It is equipped with Atlas Copco’s Rig Control System (RCS) for positioning, drilling and bolting and with the COP 1132 hydraulic rock drill, specially designed for bolt-hole drilling. The diesel hydraulic power source provides outstanding flexibility, using the diesel motor both for tramming and for drilling and bolting. Adding an optional on-board compressor and water tank creates a completely self-sufficient unit.
Features & benefits
- Low-emission, turbo-charged diesel engine for low environmental impact and powerful performance.
- MBU bolting unit for fully mechanized bolt handling and high productivity. Carries 10 bolts in its carousel and handles all commonly used bolts in the 1.5 meter to 6 meter range.
- Rig Control System (RCS) with auto-collaring for higher precision includes anti-jamming protection for better drill steel economy
- COP 1132 short, high-frequency hydraulic rock drill provides a high penetration rate with excellent drill steel economy.
Technical data
| Air system | |
|---|---|
| Adjustable speed | Yes |
| Air pressure gauge | Yes |
| Air receiver | 80 l |
| Capacity, max | 20 l/s at 7 bar |
| Hydraulic driven axial piston motor | 10 cc |
| Boom | |
| Boom | BUT 35HBE |
| Boom extension, max | 1600 mm |
| Feed roll-over | 360 |
| Lifting angle, max | +65/-30 |
| Swinging angle, max | ±45 |
| Weight, boom only | 2870 kg |
| Feed extension | 0 - 1000 mm |
| Bolting unit | |
| Bolt length | 1.5 - 6 m |
| Bolt types | Adapted for all commonly used bolts on the market, see optional equipment |
| Bolting unit | Mechanical Bolt Unit MBU |
| Chain feed | Adapted according to bolt length |
| Drill steel and coupling | According to MBU, delivered with rig |
| Face plates, rectangular, max size | 150x150 mm |
| Face plates, round, max size, diameter | 200 mm |
| Magazine capacity | 10 bolts |
| Carrier | |
| Cabin, FOPS-approved, noise level <80 dB(A) | Optional |
| Cabin, FOPS-approved, noise level <85 dB(A) | N/A |
| Fixed seat for operating | Optional |
| Fixed seat for tramming | Yes |
| Air conditioning unit, with heating function | Optional |
| Engine | Deutz 6-cylinder, TCD 2013 L06 (Tier 3/Stage IIIA) |
| Power rating | 173 kW at 2300 rpm |
| Torque | 907 Nm at 1500 rpm |
| Articulated steering | ±38 steering angle |
| All-wheel drive | Yes |
| Hydrostatic power steering system | Yes |
| Transmission | Hydrodynamic, Dana/Clark 24000 |
| Axle, front | Dana 176 |
| Axle, rear | Dana 176, ± 8 oscillation |
| Differential lock on front axle | Automatic |
| Tires | 14.00xR24 |
| Hydraulic jacks, front | 2 extendable |
| Hydraulic jacks, rear | 2 |
| Service brakes | 2 separate circuits |
| Emergency and parking brakes | SAHR |
| Fuel tank, volume | 400 l |
| Exhaust catalyser | Yes |
| Silencer | Yes |
| Electrical system | 24 Volt |
| Batteries | 2x125 Ah |
| Tramming lights | 8x70 W, 24 V DC |
| Spotlight | 1x70 W, 24 V |
| Brake lights | Yes |
| Illuminated stairs for platform | Yes |
| Fire extinguisher | Yes |
| Central lubrication system | Yes |
| Spirit level | One for longitudinal and one for sideways |
| Horn | Yes |
| Beacon | Yes |
| Reverse alarm | Yes |
| Shelf for drill bits and tools | Yes |
| Manual rig washing kit | Yes |
| Bolt/rod holder | Yes |
| Boltrack | Yes |
| Dual controls for cable/hose reel | Yes |
| Control panel for roof, jacks and cable reel | Yes |
| Gradeability at max. load on drive wheels | 1:4 |
| Rock drill lubrication kit | Manual (88) |
| Control system | |
| Control system | Rig Control System, RCS |
| Electronic control panel | Adjustable with color display |
| Transfer of data and back-up settings | PC-card |
| Integrated diagnostic system | Yes |
| Dimensions and weight | |
| Width, without bolt rack | 2501 mm |
| Height, standard | 3093 mm |
| Length | 14207 mm with MBU34.3 |
| Ground clearance | 375 mm |
| Turning radius, inner | 4750 mm |
| Turning radius, outer | 7500 mm |
| Electrical system | |
| Total installed power | N/A |
| Main motors | N/A |
| Voltage | N/A |
| Frequency | N/A |
| Starting method | N/A |
| Overload protection for electric motors | N/A |
| Digital volt/amperage meter in electrical cabinet | N/A |
| Phase sequence indicator | N/A |
| Earth fault indicator | N/A |
| Battery charger | N/A |
| Transformer | N/A |
| Cable reel, diameter | N/A |
| Limit switch for cable reel | N/A |
| Rain cap(s) for main electrical motor(s) | N/A |
| Earth connectors (EMC grounding straps) | N/A |
| Hydraulic system | |
| Hydraulic pumps | 1 unit with 4 pumps |
| Pumps unloaded at start | Yes |
| Hydraulic oil tank volume | 200 - 250 l |
| Low oil level indicator | Yes |
| Oil temperature gauge on oil tank | Yes |
| Electrical oil filling pump | Yes |
| Oil filter indicator | Yes |
| Oil/water cooler in stainless steel | Yes |
| Water cooled oil | Yes |
| Hydraulic oil | Mineral |
| Filtration | 16 µm |
| Hydraulic oil thermostat | Yes |
| System pressure, max | 150 - 230 bar |
| Water system | |
| Water inlet pressure, min | 2 bar |
| Water pressure gauge | Yes |
| Water flow guard | Yes |
| Internal water tank | Yes |
| Water pressure switch | Yes |
| Hydraulic drive, axial piston motor | 5 cc 3 |
| Capacity, max | 80 l/min at 7 bar |
| Rock drill | |
| Rock drill | COP 1132 |
Atlas Copco Drill rigs and rock drills (AC Drill rigs and rock drills ) Robbins 44RH C: Raiseboring Machine
Building on the proven design of our low profile and light weight raise drills, the Robbins 44RH C adds higher torque and thrust to a small diameter raise drill. The 44RH C is a versatile and high production raise drill, for raise requirements in the smaller diameter range.
Features & benefits
- The sturdy worktable is available with a manual or a hydraulic wrenching system for fast and reliable pipe threading
- The entire drive train features a hollow centre, enabling efficient transmission of any flushing media to clear the pilot hole
- The Robbins raise drills apply to the well established and proven Atlas Copco Rig Control System (RCS) which adds reliability and user friendliness
Technical data
| Operational data - Derrick | |
|---|---|
| Raise diameter, nominal | 1.5 m |
| Raise diameter, range | 1 - 1.8 m |
| Raise lenght, nominal | 340 m |
| Raise lenght maximum | 610 m |
| Maximum torque, reaming | 75 kNm |
| Maximum torque, break out | 96 kNm |
| Reaming thrust | 2000 kN |
| Stroke | 1710 mm |
| RPM, pilot | 0 - 49 rpm |
| RPM, reaming | 0 - 16 rpm |
| RPM, reaming (reduced torque) | 16 - 25 rpm |
| Traverse rate, fast traverse rate | 5.9 m/min |
| Traverse rate, feed rate | 3 m/min |
| Bailing air (@ 7bar/100 psi) | 13 m³/min |
| Bailing, water | 450 l/min |
| Electrical power supply (50/60 Hz) | 198/227 kW / 266/304 HP |
| Electrical voltage (50/60 Hz) | 400-1 000 V |
| Electrical frequency | 50 - 60 Hz |
| Electrical power requirement (50/60 Hz) | 198/227 kVA |
| Drill pipe diameter | 203 mm |
| Drill pipe diameter optional | 254 mm |
| Drill pipe length s/s | 1219 mm |
| Pilot hole diameter | 229 mm |
| Pilot hole optional diameter | 279 mm |
| Cooling water (at 25ºC / 77°F inlet temperature) | 60 l/min |
| Measurements & weights - Derrick | |
| Height extend | 3540 mm |
| Height retracted | 3540 mm |
| Width | 17880 mm |
| Width piploader included | 3120 mm |
| Depth | 1755 mm |
| Weight | 9900 kg |
| Weight pipeloader included | 10400 kg |
| Drill angle (from horizontal) | 90-60 ºangle |
| Measurements & weights - Power pack | |
| Length | 3300 mm |
| Height | 1690 mm |
| Width | 1600 mm |
| Weight | 4700 kg |
Atlas Copco Drill rigs and rock drills (AC Drill rigs and rock drills ) Robbins 123RH C: Raiseboring Machine
Designed for large diameter and long hole raise boring applications, the Robbins 123RH C is a very powerful raise drill. The 123RH C is designed for large diameter raises, ranging from 3.1 m up to 6.0 m (10-20 ft.), making it the preferred choice for sinking shafts in mining applications or in civil engineering applications.
Features & benefits
- Dual hydraulic pumps for high machine availability
- A gearbox incorporated in a barrel allows the drive train to be disassembled into smaller components without losing the preload of the main bearings. This saves time during maintenance & transportation
- A sliding fork worktable wrench in combination with the semi-automatic drivehead wrench eliminates the need to handle heavy wrenches
Technical data
| Operational data - Derrick | |
|---|---|
| Raise diameter, nominal | 5 m |
| Raise diameter, range | 3.1 - 6 m |
| Raise lenght, nominal | 900 m |
| Raise lenght maximum | 1100 m |
| Maximum torque, reaming | 540 kNm |
| Maximum torque, break out | 700 kNm |
| Reaming thrust | 8923 kN |
| Stroke | 2160 mm |
| RPM, pilot | 0 - 58 rpm |
| RPM, reaming | 0 - 7 rpm |
| RPM, reaming (reduced torque) | 7 - 14 rpm |
| Traverse rate, fast traverse rate | 1.7 m/min |
| Traverse rate, feed rate | 0.3 m/min |
| Bailing air (@ 7bar/100 psi) | 25 m³/min |
| Bailing, water | 800 l/min |
| Electrical power supply (50/60 Hz) | 580/650 kW / 789/884 HP |
| Electrical voltage (50/60 Hz) | 380-1000 V |
| Electrical frequency | 50 - 60 Hz |
| Electrical power requirement (50/60 Hz) | 706/791 kVA |
| Drill pipe diameter | 333 mm |
| Drill pipe length s/s | 1524 mm |
| Pilot hole diameter | 381 mm |
| Cooling water (at 25ºC / 77°F inlet temperature) | 160 l/min |
| Measurements & weights - Derrick | |
| Height extend | 5700 mm |
| Height retracted | 4100 mm |
| Width | 2300 mm |
| Width piploader included | 3800 mm |
| Depth | 2700 mm |
| Weight | 30400 kg |
| Weight pipeloader included | 32000 kg |
| Drill angle (from horizontal) | 90-60 ºangle |
| Measurements & weights - Drive pack | |
| Length | 3400 mm |
| Height | 1800 mm |
| Width | 1900 mm |
| Weight | 7100 kg |
| Measurements & weights - Thrust pack | |
| Length | 2300 mm |
| Height | 1500 mm |
| Width | 1600 mm |
| Weight | 2800 kg |
Drill rigs / Dimension stone equipment / Hydraulic drill rigs/ Rock Buggy/ atlas copco
Rock Buggy
Surface drill rig for marble, granite, sandstone and limestone in the dimension stone industry
Tailor-made for the dimension stone industry
With a low Total Cost of Ownership, high drilling capacity and a drilling speed up to 2 m/min, this rig is perfectly suited for operations in the dimension stone industry.
Parallel and straight holes means high quality output
Great rig stability and guide rails will ensure perfectly aligned and straight holes in every operation.
High drilling capacity means excellent productivity
Features like anti-jamming system, guide rails and 3-way steering ensures high quality output and excellent productivity.
Boost your productivity
Product description
Rock Buggy is a high quality, high capacity hydraulic tophammer drill rig for the dimension stone industry. This compact, four-wheel drive rig, is tailor-made for marble, granite and sandstone quarries. It is capable of drilling exceptionally straight, vertical as well as horizontal holes. Combining the rig’s stability with an anti-jamming system and guide rails, ensures holes are parallel to each other and perfectly aligned. Thanks to its high production capacity and low fuel consumption, the rig assures a very low total cost of ownership. The rig is equipped with a cable remote control as an option which allows safe operating conditions.
Quick facts
TECHNICAL DATA
Main application area | Dimension stone industry |
Drilling method | Tophammer |
Rock drill/DTH hammer size | DF 500X ; DF 530X |
Hole diameter | 28 mm - 45 mm |
Maximum hole depth | 9 m |
Engine | 139 kW |
Cabin | No |
Air capacity (FAD) | 21,73 l/s |
@ pressure | 6 bar |
Note | Product variations apply. See brochure for more information. |
TRANSPORT DIMENSIONS
Height | 2 380 mm |
Length | 5 900 mm |
Width | 2 200 mm |
Weight | 5 900 kg |
SpeedROC 1F/ Hydraulic drill rigs /Drill rigs Dimension stone equipment/atlas copco
SpeedROC 1F
Surface drill rig for the dimension stone industry
Tailor-made for the dimension stone industry
Parallel and straight holes means high quality output
High drilling capacity means excellent productivity
Big capacity in a small unit
Product description
SpeedROC 1F is a high quality, high capacity hydraulic tophammer drill rig for the dimension stone industry. This compact, four-wheel drive rig, is tailor-made for marble, granite and sandstone quarries. It is capable of drilling exceptionally straight, vertical as well as horizontal holes. Combining the rig’s stability with an anti-jamming system and guide rails, ensures holes are parallel to each other and perfectly aligned. Thanks to its high production capacity and low fuel consumption, the rig assures a very low total cost of ownership. The rig is equipped with a cable remote control as an option which allows safe operating conditions.
Quick facts
TECHNICAL DATA
Main application area | Dimension stone industry |
Drilling method | Tophammer |
Rock drill/DTH hammer size | COP DS5 |
Hole diameter | 33 mm - 52 mm |
Maximum hole depth | 9 m |
Engine | 82 kW |
Cabin | No |
Air capacity (FAD) | 22 l/s |
@ pressure | 6 bar |
Note | Product variations apply. See brochure for more information. |
TRANSPORT DIMENSIONS
Height | 2 380 mm |
Length | 5 900 mm |
Width | 2 200 mm |
Weight | 5 900 kg |
Downloads
Drilling speed: up to 2 m/min
SpeedROC 2F
Surface drill rig for marble, granite, sandstone and limestone in the dimension stone industry
Fast drilling and positioning offers high productivity
360° carrier rotation and extensive boom reach means large coverage area
Outstanding terrainability and low fuel consumption means efficiency in operations
SpeedROC 2F video
High productivity all-in-one
Product description
Reliable SpeedROC 2F is a productive drill rig for the dimension stone industry. It is highly productive thanks to its long reach and fast positioning. This versatile machine has a flexible drilling capacity and excellent tramming stability. It is the perfect choice for granite, marble and limestone quarries.
Quick facts
TECHNICAL DATA
Main application area | Dimension stone industry |
Drilling method | Tophammer |
Rock drill/DTH hammer size | DF 500X ; DF 530X |
Hole diameter | 28 mm - 45 mm |
Maximum hole depth | 9 m |
Engine | 139 kW |
Cabin | Yes |
Air capacity (FAD) | 28,31 l/s |
@ pressure | 8 bar |
Note | Product variations apply. See brochure for more information. |
TRANSPORT DIMENSIONS
Height | 3 300 mm |
Length | 11 000 mm |
Width | 2 550 mm |
Weight | 26 100 kg |
Downloads
SpeedROC D30
SpeedROC D30 redefines the way you drill in the dimension stone quarries for the wire-saw application. it is capable of drilling horizontal holes with a ground clearance of just 8 cm from center of the hole for both right and left feed directions.
Surface drill rig for the dimension stone industry
Tailor-made for the dimension stone industry
Drills straight holes just 8 cm from the ground to the hole center
Quick positioning time and low fuel consumption
Speed up your profits
Product description
SpeedROC D30 is a versatile and flexible drill rig, tailor-made for the dimension stone industry. It is capable of drilling straight, vertical and horizontal holes that enable wire cutting. Tramming, rotation and feed is powered by an on-board engine. Together with a well-matched, external compressor unit, they run the down-the-hole hammer. SpeedROC D30's special design makes it capable of drilling horizontal holes with minimum ground clearance from both right and left directions.
Quick facts
TECHNICAL DATA
Main application area | Dimension stone industry |
Drilling method | Tophammer |
Rock drill/DTH hammer size | COP 20 ; COP 35 |
Hole diameter | 70 mm - 105 mm |
Maximum hole depth | 9 m |
Engine | 26 kW |
Cabin | No |
Air capacity (FAD) | 0 l/s |
@ pressure | 0 bar |
Note | External compressor to be used. |
Hydraulic drill rigs
Products for drilling operations in dimension stone quarries
Rock Buggy
Surface drill rig for marble, granite, sandstone and limestone in the dimension stone industry
- Drilling method : Tophammer
- Rock drill/DTH hammer size : DF 500X ; DF 530X
- Hole diameter : 28 mm - 45 mm
SpeedROC 1F
Surface drill rig for marble, granite, sandstone and limestone in the dimension stone industry
- Drilling method : Tophammer
- Rock drill/DTH hammer size : COP DS5
- Hole diameter : 33 mm - 52 mm
SpeedROC 2F
Surface drill rig for marble, granite, sandstone and limestone in the dimension stone industry
- Drilling method : Tophammer
- Rock drill/DTH hammer size : DF 500X ; DF 530X
- Hole diameter : 28 mm - 45 mm
SpeedROC D30
Surface drill rig for marble, granite, sandstone and limestone in the dimension stone industry
- Drilling method : Tophammer
- Rock drill/DTH hammer size : COP 20 ; COP 35
- Hole diameter : 70 mm - 105 mm
SpeedCut 75
TECHNICAL DATA
Main application area | Dimension stone industry ; Civil engineering |
Cutting method | Diamond wire cutting |
Electrical power needed | 115 kW |
Variable speed | Yes |
Linear speed | 0 m/s - 45 m/s |
Flywheel diameter | 1 000 mm |
TRANSPORT DIMENSIONS
Height | 1 750 mm |
Length | 3 000 mm |
Width | 1 520 mm |
Weight | 2 570 kg |
Downloads
SpeedCut 100/atlas copco
Wire cutting machines
We provide the fastest wire cutting machines on the market
SpeedCut 100
Diamond wire cutting machine for marble, granite, sandstone and limestone
- Cutting method : Diamond wire cutting
- Electrical power needed : 153 kW
- Variable speed : Yes
SpeedCut 100
Diamond wire cutting machine for marble, granite, sandstone and limestone
Highest cutting capacity on the market
Low wire consumption
Full control of the cutting process
The fastest cutting machine on the market
Product description
SpeedCut, the fastest diamond wire cutting machine on the market is a high productivity product for the dimension stone industry. As the fastest machine of its kind, SpeedCut enables you to cut at speeds up to 45 m/s. A unique, patented wire tensioning system makes it possible to combine high cutting speed with low wire consumption by utilizing load cells technique.
Quick facts
TECHNICAL DATA
Main application area | Dimension stone industry ; Civil engineering |
Cutting method | Diamond wire cutting |
Electrical power needed | 153 kW |
Variable speed | Yes |
Linear speed | 0 m/s - 45 m/s |
Flywheel diameter | 1 000 mm |
TRANSPORT DIMENSIONS
Height | 1 750 mm |
Length | 3 000 mm |
Width | 1 520 mm |
Weight | 2 570 kg |
Atlas Copco Products
As a leading supplier of rock excavation equipment for more than 140 years, we have gained considerable experience and knowledge of mining techniques that are practiced across the globe.
Mining and construction products and equipment
Whether you need to excavate, transport or process ore or demolition more efficiently, our complete portfolio of surface and underground mining equipment sets the standard in an increasingly competitive industry. Our offering covers rock drilling, cutting, loading and hauling, ventilation and materials handling equipment, all supported by round-the-clock service, rock drilling tools and technical expertise.
Dimension stone equipment
We provide world leading products and services for the extraction of marble, granite, limestone and sandstone
Safety first
For us, safety always comes first. Our dimension stone industry products complies with the most strict safety regulations.
For every operation
We provide tailor-made products for every drilling and wire cutting operation needed to extract raw material in a dimension stone quarry.
Sustainable material
The output from a dimension stone quarry is 100% reusable. It can be salvaged for new construction, used as paving or crushed for use as aggregates.
We Recommend
Best Price Hard Rock Mine Dth Drill Rig Kt25 Automatic Mining Drilling Machine for Sale
$236,300.00-236,800.00
New Arrivals
New products from manufacturers at wholesale prices
